DMS Seals Wholesale pneumatic seals online factory for pneumatic equipment

Company Advantages
1. The unique outline feature is one of the most important strengths for pneumatic seals online .
2. pneumatic seals online exceed other similar products due to its design.
3. pneumatic seals online exceed other similar products with its design.
4. pneumatic seals online made from materials are especially fit for the usage in field.
5. pneumatic seals online are recognized for their good qualities such as .
6. With the assistance of , pneumatic seals online has gained its popularity in the market.
7. The unique pneumatic seals online and commercial value of have made it a hot product in China.
8. Dms Seals Technology Co.,limited will greatly value every suggestion from customers and make accordingly measures to improve.
9. DMS Seals perseveringly carries out pneumatic seals online which will make a great achievement.
10. Dms Seals Technology Co.,limited's commitment is to provide innovative localized pneumatic seals online products that play an important role in global customers.
11. Dms Seals Technology Co.,limited can ensure the fastest and most accurate delivery date for pneumatic seals online .
12. Dms Seals Technology Co.,limited has designed and developed a batch of pneumatic seals online products that are deeply loved by customers.

1. Installation Recommendation

2. Installation Sizes

Bore Diameter                         DN H9			Groove Diameter	Groove Width	Radius	Radial Clearance                S max.			O-Ring Cross-Section
Standard Application	Light Application	Heavy Duty Application	d1 h9	L1+0.2	R1	10MPa	20MPa	40MPa	d2
8-14.9	15-39.9	-	DN-4.9	2.2	0.4	0.3	0.20	0.15	1.78
15-39.9	40-79.9	-	DN-7.5	3.2	0.6	0.4	0.25	0.15	2.62
40-79.9	80-132.9	15-39.9	DN-11.0	4.2	1.0	0.4	0.25	0.20	3.53
80-132.9	133-329.9	40-79.9	DN-15.5	6.3	1.3	0.5	0.30	0.20	5.33
133-329.9	330-699.9	80-132.9	DN-21.0	8.1	1.8	0.6	0.35	0.25	7.00
330-669.9	670-99.9	133-329.9	DN-24.5	8.1	1.8	0.6	0.35	0.25	7.00
670-999.9	≥1000	330-669.9	DN-28.0	9.5	2.5	0.7	0.50	0.30	8.40
≥1000	≥1000	≥1000	DN-38.0	13.8	3.0	1.0	0.70	0.60	12.00

3. Application and properties

Standard double acting seal. Suitable for reciprocating motion, allowing larger extrusion clearances, has wide application. Dynamic and static sealing property are excellent, be able to work in dusty condition. Low friction, simple groove, strong adaptability to work conditions.

4. Standard materials

Sealing ring: filled PTFE

O-Ring: NBR / FKM

5. Working Conditions

Working  Conditions
Diameter Range	Pressure Range	Temperature Range	Speed	Medium
3 - 1600mm	0 - 60MPa	-45℃ +200℃	15 m/s	hydraulic oil, flame retardant liquid, water and others

6. Installation Dimensions

Bore Dia.	Groove Dia.	Groove Width	Order No.	O-Ring Dimensions
DN H9	d1 h9	L1+0.2
8 10 12	3.1 5.1 7.1	2.2 2.2 2.2	GSF8*3.1*2.2 GSF10*5.1*2.2 GSF12*7.1*2.2	2.90*1.78 4.80*1.8 6.70*1.8
14 15 15	9.1 10.1 7.5	2.2 2.2 3.2	GSF14*9.1*2.2 GSF15*10.1*2.2 GSF15*7.5*3.2	8.75*1.8 7.59*2.62 8.75*1.8
16 16 18	11.1 8.5 13.1	2.2 3.2 2.2	GSF16*11.1*2.2 GSF16*8.5*3.2 GSF18*13.1*2.2	10.82*1.78 7.59*2.62 12.42*1.78
18 20 20	10.5 15.1 12.5	3.2 2.2 3.2	GSF18*10.5*3.2 GSF20*15.1*2.2 GSF20*12.5*3.2	9.19*2.62 14.00*1.78 12.37*2.62
24 24 25	19.1 16.5 17.5	2.2 3.2 3.2	GSF24*19.1*2.2 GSF24*16.5*3.2 GSF25*17.5*3.2	18.77*1.78 15.54*2.62 17.12*2.62
25 28 28	14 20.5 17	4.2 3.2 4.2	GSF25*14*4.2 GSF28*20.5*3.2 GSF28*17*4.2	13.87*3.53 20.29*2.62 15.47*3.53
30 30 32	22.5 19 24.5	3.2 4.2 3.2	GSF30*22.5*3.2 GSF30*19*4.2 GSF32*24.5*3.2	21.89*2.62 26.70*1.78 23.47*2.62

Company Features
1. The reputation of DMS Seals is spread almost all over the world. Dms Seals Technology Co.,limited is professional in producing pneumatic seals online , including Piston Seals. Dms Seals Technology Co.,limited is a modern enterprise dedicated to the design and manufacture power seal pistons . Dms Seals Technology Co.,limited has grown to be a professional manufacturer and supplier for its hydraulic oil seal manufacturers . By means of scientific and flexible management advantages, DMS Seals achieves the greatest value of hydraulic cylinder shaft seals .
2. Our company has been recognized as an implementer of superior quality and has been awarded many times for our brand equity, business results, and innovation. We have a well-equipped plant. It is equipped with state-of-the-art automation technology, computerized inspection, and functional testing equipment, which guarantees the quality of the products. Our manufacturing team plays an essential role in our business growth. They can address quality, cost and delivery issues by redesigning manufacturing systems to reduce lead times and increase flexibility. Over the years, we have been fortunate to attract some of the most talented professionals in our industry. They are dedicated to proving the very best service and response levels in the industry.
3. We have set out to increase our positive impact on the environment. We strive to ensure that we source our ingredients responsibly and sustainably. We work hard to the sustainability of water management. We have improved the technology of water utilization in order to prevent excessive utilization of water sources. We make sure that every shipment is delivered in the least possible time. Customer's time and money are very precious for us; so we make sure that you get commendable services for your time and money. We have a simple goal: to ensure a process that works seamlessly so that we can constantly create long-term financial, physical and social value. We will always abide by ethical marketing rules. We uphold fair trade practices that do not harm clients' interests and rights. We'll never initiate any vicious market competition or partake in any business activities pushing up the price.

DMS Seals Wholesale pneumatic seals online factory for pneumatic equipment

pneumatic seals online

Type:
