GSD - PTFE Hydraulic pneumatic Piston Seal with NBR/FKM O-Ring

Standard Application

Light Application

Heavy Duty Application

d1 h9

L1+0.2

R1

10MPa

20MPa

40MPa

d2

8-16.9

17-26.9

--

DN-4.9

2.2

0.4

0.30

0.20

0.15

1.78

17-26.9

27-59.9

--

DN-7.3

3.2

0.6

0.40

0.25

0.15

2.62

27-59.9

60-199.9

17-26.9

DN-10.7

4.2

1.0

0.50

0.30

0.20

3.53

60-199.9

200-255.9

27-59.9

DN-15.1

6.3

1.3

0.70

0.40

0.25

5.33

200-255.9

256-669.9

60-199.9

DN-20.5

8.1

1.8

0.80

0.60

0.35

7.00

256-669.9

670-999.9

200-669.9

DN-24.0

8.1

1.8

0.90

0.70

0.40

7.00

670-999.9

--

256-669.9

DN-28.0

9.5

2.5

1.00

0.80

0.60

8.40

--

1000-2000

--

DN-28.0

9.5

2.5

1.00

0.80

0.60

8.40

--

--

670-999.9

DN-38.0

13.8

3.0

1.20

0.90

0.60

12.00

1000-2700

--

--

DN-38.0

13.8

3.0

1.20

0.90

0.60

12.00

Diameter Range

Pressure Range

Temperature Range

Speed

Medium

3-1600mm

0-60MPa

-45℃ +200℃

15 m/s

hydraulic oil, flame retardant liquid, water and others

D H9

d1 h9

L1+0.2

9
10
12

4.1
5.1
7.1

2.2
2.2
2.2

GSD9*4.1*2.2
GSD10*5.1*2.2
GSD12*7.1*2.2

3.68*1.78
4.80*1.8
6.70*1.8

15
18
20

10.1
10.7
15.1

2.2
3.2
2.2

GSD15*10.1*2.2
GSD18*10.7*3.2
GSD20*15.1*2.2

9.25*1.78
9.19*2.62
14.0*1.78

20
22
25

12.7
14.7
17.7

3.2
3.2
3.2

GSD20*12.7*3.2
GSD22*14.7*3.2
GSD25*17.7*3.2

12.37*2.62
13.94*2.62
17.12*2.62

27
28
30

16.3
17.3
19.3

4.2
4.2
4.2

GSD27*16.3*4.2
GSD28*17.3*4.2
GSD30*19.3*4.2

15.47*3.53
16.4*3.53
18.66*3.53

32
32
35

24.7
21.3
24.3

3.2
4.2
4.2

GSD32*24.7*3.2
GSD32*21.3*4.2
GSD35*24.3*4.2

23.47*2.62
20.22*3.53
23.40*3.53

36
38
40

25.3
27.3
32.7

4.2
4.2
3.2

GSD36*25.3*4.2
GSD38*27.3*4.2
GSD40*32.7*3.2

24*3.53
26*3.53
31.42*2.62

40
45
48

29.9
34.3
37.3

4.2
4.2
4.2

GSD40*29.3*4.2
GSD45*34.3*4.2
GSD48*37.3*4.2

28.17*3.53
32.92*3.53
36.09*3.53

50
50
52

39.3
34.9
41.3

4.2
6.3
4.2

GSD50*39.3*4.2
GSD50*34.9*6.3
GSD52*41.3*4.2

37.70*3.53
32.69*5.33
40.87*3.53

55
60
63

44.3
44.9
52.3

4.2
6.3
4.2

GSD55*44.3*4.2
GSD60*44.9*6.3
GSD63*52.3*4.2

44.04*3.53
43.82*5.33
50.39*3.53

63
64
65

47.9
48.9
49.9

6.3
6.3
6.3

GSD63*47.9*6.3
GSD64*48.9*6.3
GSD65*49.9*6.3

46.99*5.33
46.99*5.33
46.99*5.33

70
70
75

59.3
54.9
59.9

4.2
6.3
6.3

GSD70*59.3*4.2
GSD70*54.9*6.3
GSD75*59.9*6.3

56.74*3.53
53.34*5.33
56.52*5.33

80
80
85

64.9
59.5
69.9

6.3
8.1
6.3

GSD80*64.9*6.3
GSD80*59.5*8.1
GSD85*69.9*6.3

62.87*5.33
58*7.0
69.22*5.33

90
90
95

74.9
69.5
79.9

6.3
8.1
6.3

GSD90*74.9*6.3
GSD90*69.5*8.1
GSD95*79.9*6.3

72.39*5.33
68*7.0
78.74*5.33

95
100
100

74.5
84.9
79.5

8.1
6.3
8.1

GSD95*74.5*8.1
GSD100*84.9*6.3
GSD100*79.5*8.1

73*7.0
81.92*5.33
78*7.0

110
120
125

94.9
104.9
104.5

6.3
6.3
6.3

GSD110*94.9*6.3
GSD120*104.9*6.3
GSD125*109.9*6.3

91.44*5.33
104.14*5.33
107.32*5.33
