Application Scope
Dms Seals's
O-ring Seal can be widely used in various fields.Dms Seals is dedicated to solving your problems and providing you with one-stop and comprehensive solutions.
Company Advantages1. The material of DMS Seal Manufacturer hydraulic piston seals sizes is controlled to be just right.
2. The design of hydraulic piston seals is very innovative.
3. hydraulic piston seals takes on by elegant shape to meet high demands.
4. Dms Seals Technology Co.,limited can offer customers all kinds of hydraulic piston seals with different sizes and colors.
5. The product is dustproof. The surface of this product has a special coating to prevent adhesion of dust and oil smoke.
6. The product features enough safety. It ensured that there were no sharp edges on this product unless they are required.
7. The product features versatility. It is suitable for grilling meat, smaller shellfish or vegetables. This size of it means it will fit pretty much any barbecue.
8. The product is well known for its hardness. It has the ability to resist various kinds of permanent shape change such as scratch, and indentation.
9. The product is highly automatic. It will automatically switch on when low water level, and switch off when high water level.
10. The quality of hydraulic piston seals is always the thing Dms Seals Technology Co.,limited has been concerned about.
11. The service of DMS Seal Manufacturer promotes the popularity of the brand in the industry.
12. Large factory and enough well-trained workers can add up to completely guarantee on-time delivery for hydraulic piston seals .
Installation Recommendation
![undefined undefined]()
Installation Sizes
Bore Diameter | Groove Diameter | Groove Width | Radius | Radial Clearance S max. |
D H8 | d h8 | L1+0.2 | R1 | 16MPa | 26MPa | 32MPa | 40MPa |
55.0-149.9 | D-10.0 | 10.0 | 0.4 | 0.60 | 0.50 | 0.40 | 0.40 |
150.0-244.9 | D-12.5 | 12.5 | 0.4 | 0.75 | 0.65 | 0.55 | 0.50 |
245.0-500.0 | D-15.0 | 15.0 | 0.8 | 0.75 | 0.65 | 0.55 | 0.50 |
500.1-760.0 | D-17.5 | 17.5 | 1.2 | 0.75 | 0.65 | 0.55 | 0.50 |
760.1-999.9 | D-20.0 | 20.0 | 1.2 | 0.80 | 0.70 | 0.60 | 0.55 |
≧1000 | D-20.0 | 20.5 | 1.2 | 0.80 | 0.70 | 0.60 | 0.55 |
Application and properties
Applied to the hydraulic cylinder of heavy machinery and metallurgical equipment. Pressure resistance and corrosion resistance are strong, good thermal conductivity,structure anti-distortion, low friction, no crawling phenomenon.
Sealing ring: filled PTFE
O-Ring: NBR / FKM
Working Conditions
Working Conditions |
Diameter Range | Pressure Range | Temperature Range | Speed | Medium |
3-1600mm | 0-60MPa | -30℃+100℃ | 5 m/s | hydraulic oil, flame retardant liquid, water and others |
Installation Dimensions
Bore Dia. | Groove Dia. | Groove Width | Order No. |
D H8 | d h8 | L+0.2 |
55
60
70 | 40
45
55 | 10
10
10 | GSF-W55*40*10
GSF-W60*45*10
GSF-W70*55*10 |
80
90
100 | 60
70
80 | 10
10
10 | GSF-W80*60*10
GSF-W90*70*10
GSF-W100*80*10 |
110
115
120 | 90
95
100 | 10
10
10 | GSF-W110*90*10
GSF-W115*95*10
GSF-W120*100*10 |
130
140
150 | 110
120
125 | 10
10
12.5 | GSF-W130*110*10
GSF-W140*120*10
GSF-W150*125*12.5 |
160
165
170 | 135
140
145 | 12.5
12.5
12.5 | GSF-W160*135*12.5
GSF-W165*140*12.5
GSF-W170*145*12.5 |
180
185
190 | 155
160
165 | 12.5
12.5
12.5 | GSF-W180*155*12.5
GSF-W185*160*12.5
GSF-W190*165*12.5 |
200
205
210 | 175
180
185 | 12.5
12.5
12.5 | GSF-W200*175*12.5
GSF-W205*180*12.5
GSF-W210*185*12.5 |
215
220
225 | 190
195
200 | 12.5
12.5
12.5 | GSF-W215*190*12.5
GSF-W220*195*12.5
GSF-W225*200*12.5 |
230
240
245 | 205
215
215 | 12.5
12.5
15 | GSF-W230*205*12.5
GSF-W240*215*12.5
GSF-W245*215*15 |
Company Features1. As a major research and development enterprise of China’s hydraulic piston seals , Dms Seals Technology Co.,limited occupies a leading position in the industry. In piston seals business, Dms Seals Technology Co.,limited enjoys a high popularity. Dms Seals Technology Co.,limited is one of the key enterprises of national o-ring seal industry, whose leading product is hydraulic piston seals sizes . Due to the fast business development, more and more new projects are introduced to Dms Seals Technology Co.,limited. Dms Seals Technology Co.,limited is an important producer of hydraulic piston seals .
2. DMS Seal Manufacturer continues to use technology innovation to create value of hydraulic piston seals for its customers. Dms Seals Technology Co.,limited has advanced hydraulic piston seals production equipment. Dms Seals Technology Co.,limited has a large number of world-class equipment and hydraulic piston seals production facilities. At present, most of the hydraulic piston seals series produced by us are original products in China.
3. Our mission is to create and manufacture products in innovative ways and to enable people to achieve their business objectives through the product we provide. The firm is dedicated to implementing its goal. We will work hard to provide professional and valuable customers service delivered with a sense of warmth, passion, friendliness, and team spirit. Call now! The ultimate goal of Dms Seals Technology Co.,limited is to achieve continuous improvement in product quality and service. Call now!
gsdw hydraulic piston seals spgw for pneumatic equipment DMS Seal Manufacturer
hydraulic piston seals
Type:gsdw
![DMS Seal Manufacturer-hydraulic piston seals sizes | Piston Seals | DMS Seal Manufacturer-2]()
