high end hydraulic cylinder seal compression tool for business for pressure work and sliding high speed occasions

Company Advantages
1. The production of DMS Seals hydraulic cylinder seal compression tool is completed by international advanced technology, ensuring smooth, efficient, and precise product.
2. DMS Seals hydraulic cylinder seal compression tool is made on advanced production lines and by experienced technicians.
3. DMS Seals is constructed from well-chosen raw materials.
4. The production process of DMS Seals hydraulic cylinder seal compression tool follows strictly the industry standards. .
5. The product is mildewproofed. It has been treated with mildew preventive which is effective in killing mold and some kinds of bacteria.
6. The product is known for its shock absorption. It can absorb the stress or impact on the feet, hence to offer a certain buffering effect.
7. The product causes no harm. During the production, only the low or no volatile organic compounds (VOCs) are used, and any formaldehyde is excluded.
8. The product has good breathability. It allows air to freely permeate through to maintain appropriate temperature and humidity.
9. Dms Seals Technology Co.,limited has the world's most advanced technology and testing method.
10. The maturity process technology, standardized production and strict quality control system are the guarantee of the quality of Dms Seals Technology Co.,limited's products.
11. DMS Seals can also guarantee the fast delivery time.

1. Installation Recommendation

2. Installation Sizes

Rod Diameter                         dN h9			Groove Diameter	Groove Width	Radius	Radial Clearance                S max.			O-Ring Cross-Section
Standard Application	Light Application	Heavy Duty Application	D1 H9	L1+0.2	R1	10MPa	20MPa	40MPa	d2
3-7.9	8-18.9	-	dN+4.9	2.2	0.4	0.3	0.20	0.15	1.78
8-18.9	19-37.9	-	dN+7.3	3.2	0.6	0.4	0.25	0.15	2.62
19-37.9	38-199.9	8-18.9	dN+10.7	4.2	1.0	0.4	0.25	0.20	3.53
38-199.9	200-255.9	19-37.9	dN+15.1	6.3	1.3	0.5	0.30	0.20	5.33
200-255.9	256-649.9	38-199.9	dN+20.5	8.1	1.8	0.6	0.35	0.25	7.00
256-649.9	650-999.9	200-255.9	dN+24.0	8.1	1.8	0.6	0.35	0.25	7.00
650-999.9	≥1000.0	256-649.9	dN+27.3	9.5	2.5	0.7	0.50	0.30	8.40
≥1000.0	-	650-999.9	dN+38.0	13.8	3.0	1.0	0.70	0.60	12.00

3. Application and properties

Applicable to high and low speed reciprocating motion and high pressure system cylinder rod sealing. Good dimensional stability, not affected by temperature, low friction, strong corrosion resistance, could work in the situation with or without lubrication, easy installation. Meet the standards of GB/T 15242.1-94 and GB/T 15242.3-94.

4. Standard materials

Sealing ring: filled PTFE

O-Ring: NBR / FKM

5. Working Conditions

Working  Conditions
Diameter Range	Pressure Range	Temperature Range	Speed	Medium
3 - 1600mm	0 - 60MPa	-45℃ +200℃	15 m/s	hydraulic oil, flame retardant liquid, water, gas

6. Installation Dimensions

Rod Dia.	Groove Dia.	Groove Width	Order No.	O-Ring Dimensions
dN h9	D1 H9	L1+0.2
20 20 22	27.3 30.7 29.3	3.2 4.2 3.2	GSJ20*27.3*3.2 GSJ20*30.7*4.2 GSJ22*29.3*3.2	21.89*2.62 23.39*3.53 23.47*2.62
22 25 25	32.7 32.3 35.7	4.2 3.2 4.2	GSJ22*32.7*4.2 GSJ25*32.3*3.2 GSJ25*35.7*4.2	26.57*3.53 26.64*2.62 29.74*3.53
28 30 32	38.7 40.7 42.7	4.2 4.2 4.2	GSJ28*38.7*4.2 GSJ30*40.7*4.2 GSJ32*42.7*4.2	31.34*3.53 34.52*3.53 36.09*3.53
35 36 38	45.7 46.7 53.1	4.2 4.2 6.3	GSJ35*45.7*4.2 GSJ36*46.7*4.2 GSJ38*53.1*6.3	37.69*3.53 40.87*3.53 43.82*5.33
40 40 42	50.7 55.1 57.1	4.2 6.3 6.3	GSJ40*50.7*4.2 GSJ40*55.1*6.3 GSJ42*57.1*6.3	44.04*3.53 43.82*5.33 46.99*5.33
45 45 50	55.7 60.1 60.7	4.2 6.3 4.2	GSJ45*55.7*4.2 GSJ45*60.1*6.3 GSJ50*60.7*4.2	47.22*3.53 50.17*5.33 53.57*3.53
50 55 56	65.1 70.1 66.7	6.3 6.3 4.2	GSJ50*65.1*6.3 GSJ55*70.1*6.3 GSJ56*66.7*4.2	56.52*5.33 59.69*5.33 59.92*3.53
56 56 60	71.1 76.5 75.1	6.3 8.1 6.3	GSJ56*71.1*6.3 GSJ56*76.5*8.1 GSJ60*75.1*6.3	59.69*5.33 62.87*6.99 66.04*5.33

Company Features
1. Dms Seals Technology Co.,limited is a mature manufacturing company headquartered in China. We are favored for high-quality products and incredible delivery times. Having accumulating years of experience in manufacturing of , Dms Seals Technology Co.,limited has taken its place among reliable manufacturers. With years of development, Dms Seals Technology Co.,limited has been regarded as a trustworthy manufacturer in the industry. We specialize in the design and production of . Dms Seals Technology Co.,limited has made a lot of achievements in developing and manufacturing . We have achieved much praise from competitors.
2. DMS Seals's factory has advanced production technology. The solid technology foundation for Dms Seals Technology Co.,limited further consolidates the quality of hydraulic cylinder seal compression tool . We have professional QC department to test strictly cylinder rod seal .
3. Our sustainability work is integrated into our business culture and values. In our operation, we will work to ensure that production wastes are lawfully handled and resources are fully utilized. To achieve our ambitious manufacturing eco-efficiency targets, we make positive carbon commitments. During our production, we adopt new technologies to minimize our production waste and use clean energy as possible. We have set up our sustainability practices. We aim to mitigate the impact of our activities on the environment by decreasing CO2 emissions and improving our recycling rate.
