high end hydraulic rod seal installer cost for sale

Company Advantages
1. Developed by dexterous professionals utilizing the best materials, DMS Seals hydraulic rod seal installer is fine in workmanship and attractive in design.
2. The DMS Seals offered by us is manufactured under the guidance of our experienced professionals.
3. By adopting the lean production method, DMS Seals is exquisite in detail.
4. DMS Seals hydraulic rod seal installer is delicately manufactured by excellent production team using advanced technology and sophisticated equipment.
5. DMS Seals is precisely manufactured using premium quality raw materials and advanced technology by our adroit professionals.
6. It features rapid moisture absorption. It has passed various moisture management tests through a wide array of testing methods including AATCC 195 and CNS 15659-2 L1038-2.
7. The product is highly resistant to deformation and burst. It is made of quality materials that can stand up to load and heavy weight.
8. This product is durable. It is well constructed and sturdy enough for the purpose for which it was designed for.
9. The product has the desired safety. It does not contain any harmful, toxic, and skin-irritant chemicals which may cause skin allergies.
10. It has thermal comfort. Its materials contain fibers that feature hygroscopic properties and are capable of absorbing moisture, which contributes to the thermal comfort of this product.
11. The adoption of this product will improve workers' working environment, in terms of noises, repair frequency, and control level over this product.
12. With its compact design, it takes up very small space. People can flexibly put it in any unoccupied place.
13. The design of the product plays an important role in relaxing people's minds. It will give people a good mood when they walk into the bathroom.
14. The product is easy to use. Instead of having phone owners hovering around the complicated instruction, this newly designed product features high user friendless.
15. This product showcases merchandise in an aesthetically pleasing way. It can improve the overall store experience for shoppers and increase sales turnover.

1. Installation Recommendation

2. Installation Sizes

Rod Diameter                         dN h9			Groove Diameter	Groove Width	Radius	Radial Clearance                S max.			O-Ring Cross-Section
Standard Application	Light Application	Heavy Duty Application	D1 H9	L1+0.2	R1	10MPa	20MPa	40MPa	d2
3-7.9	8-18.9	-	dN+4.9	2.2	0.4	0.3	0.20	0.15	1.78
8-18.9	19-37.9	-	dN+7.3	3.2	0.6	0.4	0.25	0.15	2.62
19-37.9	38-199.9	8-18.9	dN+10.7	4.2	1.0	0.4	0.25	0.20	3.53
38-199.9	200-255.9	19-37.9	dN+15.1	6.3	1.3	0.5	0.30	0.20	5.33
200-255.9	256-649.9	38-199.9	dN+20.5	8.1	1.8	0.6	0.35	0.25	7.00
256-649.9	650-999.9	200-255.9	dN+24.0	8.1	1.8	0.6	0.35	0.25	7.00
650-999.9	≥1000.0	256-649.9	dN+27.3	9.5	2.5	0.7	0.50	0.30	8.40
≥1000.0	-	650-999.9	dN+38.0	13.8	3.0	1.0	0.70	0.60	12.00

3. Application and properties

Applicable to high and low speed reciprocating motion and high pressure system cylinder rod sealing. Good dimensional stability, not affected by temperature, low friction, strong corrosion resistance, could work in the situation with or without lubrication, easy installation. Meet the standards of GB/T 15242.1-94 and GB/T 15242.3-94.

4. Standard materials

Sealing ring: filled PTFE

O-Ring: NBR / FKM

5. Working Conditions

Working  Conditions
Diameter Range	Pressure Range	Temperature Range	Speed	Medium
3 - 1600mm	0 - 60MPa	-45℃ +200℃	15 m/s	hydraulic oil, flame retardant liquid, water, gas

6. Installation Dimensions

Rod Dia.	Groove Dia.	Groove Width	Order No.	O-Ring Dimensions
dN h9	D1 H9	L1+0.2
20 20 22	27.3 30.7 29.3	3.2 4.2 3.2	GSJ20*27.3*3.2 GSJ20*30.7*4.2 GSJ22*29.3*3.2	21.89*2.62 23.39*3.53 23.47*2.62
22 25 25	32.7 32.3 35.7	4.2 3.2 4.2	GSJ22*32.7*4.2 GSJ25*32.3*3.2 GSJ25*35.7*4.2	26.57*3.53 26.64*2.62 29.74*3.53
28 30 32	38.7 40.7 42.7	4.2 4.2 4.2	GSJ28*38.7*4.2 GSJ30*40.7*4.2 GSJ32*42.7*4.2	31.34*3.53 34.52*3.53 36.09*3.53
35 36 38	45.7 46.7 53.1	4.2 4.2 6.3	GSJ35*45.7*4.2 GSJ36*46.7*4.2 GSJ38*53.1*6.3	37.69*3.53 40.87*3.53 43.82*5.33
40 40 42	50.7 55.1 57.1	4.2 6.3 6.3	GSJ40*50.7*4.2 GSJ40*55.1*6.3 GSJ42*57.1*6.3	44.04*3.53 43.82*5.33 46.99*5.33
45 45 50	55.7 60.1 60.7	4.2 6.3 4.2	GSJ45*55.7*4.2 GSJ45*60.1*6.3 GSJ50*60.7*4.2	47.22*3.53 50.17*5.33 53.57*3.53
50 55 56	65.1 70.1 66.7	6.3 6.3 4.2	GSJ50*65.1*6.3 GSJ55*70.1*6.3 GSJ56*66.7*4.2	56.52*5.33 59.69*5.33 59.92*3.53
56 56 60	71.1 76.5 75.1	6.3 8.1 6.3	GSJ56*71.1*6.3 GSJ56*76.5*8.1 GSJ60*75.1*6.3	59.69*5.33 62.87*6.99 66.04*5.33

Company Features
1. Dms Seals Technology Co.,limited, who started with high-end hydraulic rod seal installer , has laid a solid foundation for quality. With larger manufacture scale, Dms Seals Technology Co.,limited has made a stride in international stage. Dms Seals Technology Co.,limited is famous in the piston rod seals hydraulic industry whatever in China or in world. Dms Seals Technology Co.,limited is a hyd cylinder seals producer known for high quality. The sales network in Dms Seals Technology Co.,limited spreads across the domestic and abroad market.
2. All our technician in Dms Seals Technology Co.,limited are well trained to help customers solve problems for polyurethane hydraulic seals . we have successfully developed a variety of rod seal catalogue series. We put great emphasis on technology of hydraulic rod wipers . The standard nature of these processes permits us to fabricate .
3. Dms Seals Technology Co.,limited is committed to in filed. Inquire online! Dms Seals Technology Co.,limited carry forward the goal of and conduct a step-by-step . Inquire online! Developing DMS Seals into a global brand in pneumatic cylinder rod seal industry is our pursuing goal. Inquire online! Complying with the tenet of rod seal tool helps DMS Seals grow more in this market. Inquire online! Dms Seals Technology Co.,limited is committed to strengthening the spirit of . Inquire online!
