high end pneumatic rubber seals factory for pressure work and sliding high speed occasions

Company Advantages
1. Such design of could potentially revolutionize pneumatic rubber seals industry.
2. The combination of materials makespneumatic rubber seals very stable with a long service life.
3. pneumatic rubber seals from Dms Seals Technology Co.,limited mainly uses high-end materials.
4. Strict quality standards are established in the inspection process to ensure the high quality of products.
5. The quality of the products can stand the test of time.
6. The long-lasting and stable performance makes this product a great advantage in the industry.
7. Real-time processing of orders and sales can be guaranteed in Dms Seals Technology Co.,limited.
8. Dms Seals Technology Co.,limited has excellent customer service representatives available to help you out by phone.
9. Dms Seals Technology Co.,limited has been adhering to the purpose of providing quality services.

1. Installation Recommendation

2. Application and properties

The standard combination seal is suitable for a wide range of pressure work and sliding high speed occasions. Low friction, strong wear resistance.



3. Standard materials

Sealing ring: filled PTFE

O-Ring: NBR / FKM

4. Working Conditions

Working  Conditions
Diameter Range	Pressure Range	Temperature Range	Speed	Medium
6-1600mm	0-35MPa	-30℃ +200℃	1.5 m/s	general hydraulic oil, water glycol Hydraulic oil and water emulsion type hydraulic oil.



5. Installation Dimensions

Nominal Size of Packing, and Housing dimensions				Order No.
d	D	H	L +0.2
18 20 22	27 29 31	4.3 4.3 4.3	4.5 4.5 4.5	SPN18*27*4.3 SPN20*29*4.3 SPN22*31*4.3
27 31.5 47	36 40.5 60	4.3 4.3 7.3	4.5 4.5 7.5	SPN27*36*4.3 SPN31.5*40.5*4.3 SPN47*60*7.3
53 60 65	66 73 78	7.3 7.3 7.3	7.5 7.5 7.5	SPN53*66*7.3 SPN60*73*7.3 SPN65*78*7.3
70 75 80	83 88 93	7.3 7.3 7.3	7.5 7.5 7.5	SPN70*83*7.3 SPN75*88*7.3 SPN80*93*7.3
90 100 110	103.4 113.4 123.4	7.3 7.3 7.3	7.5 7.5 7.5	SPN90*103.4*7.3 SPN100*113.4*7.3 SPN110*123.4*7.3
120 130 140	133.4 143.4 153.4	7.3 7.3 7.3	7.5 7.5 7.5	SPN120*133.4*7.3 SPN130*143.4*7.3 SPN140*153.4*7.3

Company Features
1. Dms Seals Technology Co.,limited is a large enterprise integrating production, research and development, sales and service of . Dms Seals Technology Co.,limited, with outstanding capability in manufacturing pneumatic rubber seals , has become a renowned enterprise in China and overseas markets. In recent years, Dms Seals Technology Co.,limited ranks among top competitors considering the developing and manufacturing capability of . Dms Seals Technology Co.,limited is a dependable manufacturer in delivering trusted by integrating science, technology, and business expertise.
2. We have a long-term and stable market in China, the United States, Japan, Canada, etc. The R&D team has been working hard to create more products to cater to the market demands of various countries. We provide products for companies situated all over the world. We have established a huge list of clients because of our sales person's impressive network in the market. We have professional designers who are qualified with abundant experience. They can provide designing, sample making, and full-production services for customers, and can handle clients' projects in a more professional and effective way. Based on years of market expansion experience, we have become a global market player in this industry, especially in the markets of North America, Asia, and the Middle East.
3. We aim to be problem-solvers and partners, not just producers. We listen to customers and make what they want us to make. Then we deliver quickly-- minus any bureaucratic fuss. Our business is devoted to sustainability. We've implemented steps to reduce our footprint in the environment such as generating our own solar power. Our firm bears societal responsibilities. We operate according to this publicly accessible environmental policy because the institution, which communicates a preventative approach to sustainable growth.

high end pneumatic rubber seals factory for pressure work and sliding high speed occasions

pneumatic rubber seals

Type:
