hydraulic rod seals rod DMS Seal Manufacturer Brand rod seals

Diameter Range:

3-1600mm

Pressure Range:

0-60MPa

Temperature Range:

-30℃+200℃

Speed:

15m/s

Medium:

hydraulic oil, flame retardant liquid, water, gas

Inquiry

Company Advantages
1. The rod seals facility can hydraulic rod seals and you can specify piston rod seal.The high pressure seals have strong wear resistance to hard conditions
2. It is of great importance for DMS Seal Manufacturer to provide exquisite customer service. Quality control of the seals is the basis for DMS Seals
3. DMS Seal manufacturer was established in 2008 and now has more than 10 years professional experience. hydraulic rod seals,hydraulic rod seals online has many advantages, such as rod seal catalogue.
4. To reduce costs with high-efficiency work is the DMS's purpose. DMS Seal Manufacturer provides pneumatic rod seals to help reduce O Ring Manufacturers,push rod seal.
5. Seal we produced has applications in a wide range of fields, We Provides Huge Selection And Reasonable Price Of o-ring seal, hydraulic rod seals For Wholesalers.

Installation Recommendation

undefined

Application and properties

Applicable to high and low speed reciprocating motion environment, a wide range of fluids and high temperature condition. Suitable for larger gap of piston rod. Low friction, simple groove, be able to work in the medium with oil spots.

Standard materials

Sealing ring: filled PTFE

O-Ring: NBR / FKM

Working Conditions

Working Conditions
Diameter Range	Pressure Range	Temperature Range	Speed	Medium
3-1600mm	0-60MPa	-30℃+200℃	15 m/s	hydraulic oil, flame retardant liquid, water, gas

Installation Dimensions

Rod Dia.	Outer Dia.	Width	Order No.
d h9	D1 H9	L1+0.2	Order No.
40 45 50	50 55 60	4.2 4.2 4.2	GSW40504.2 GSW45554.2 GSW50604.2
50 53 55	65 63 65	6.8 4.2 4.2	GSW50656.8 GSW53634.2 GSW55654.2
55 60 60	70 70 75	6.8 4.2 6.8	GSW55706.8 GSW60704.2 GSW60756.8
63 65 65	73 75 80	4.2 4.2 6.8	GSW63734.2 GSW65754.2 GSW65806.8
67 70 70	77 80 82	4.2 4.2 6.8	GSW67774.2 GSW70804.2 GSW70856.8
75 75 80	85 90 90	4.2 6.8 4.2	GSW75854.2 GSW75906.8 GSW80904.2
80 85 90	75 100 105	6.8 6.8 6.8	GSW80956.8 GSW851006.8 GSW901056.8
95 100 106	110 115 121	6.8 6.8 6.8	GSW951106.8 GSW1001156.8 GSW1061216.8
110 115 120	125 130 135	6.8 6.8 6.8	GSW1101256.8 GSW1151306.8 GSW1201356.8
125 130 135	140 145 150	6.8 6.8 6.8	GSW1251406.8 GSW1301456.8 GSW1351506.8
140 145 150	155 160 165	6.8 6.8 6.8	GSW1401556.8 GSW1451606.8 GSW1501656.8
155 160 165	170 175 180	6.8 6.8 6.8	GSW1551706.8 GSW1601756.8 GSW1651806.8
170 175 180	185 190 200	6.8 6.8 8.1	GSW1701856.8 GSW1751906.8 GSW1802008.1

Installation Dimensions

Company Features
1. There are many successful cooperation cases with Dms Seals Technology Co.,limited for our rod seals. - hydraulic rod seals is developed using latest technology support for hydraulic rod seals.
2. Dms Seals Technology Co.,limited invests a lot in technology of O Ring Manufacturers.
3. DMS Seal Manufacturer has made some breakthroughs in improving quality of the o-ring seal. - Relentless pursuit of quality excellence is significant to Dms Seals Technology Co.,limited. Please contact us!

we welcome custom designs and ideas and is able to cater to the specific requirements. for more information, please visit the website or contact us directly with questions or inquiries.
