hydraulic seals distributors for business for pressure work and sliding high speed occasions

Company Advantages
1. Having been finely processed, hydraulic seals distributors can be widely used in many different places. DMS Seal manufacturer provides good quality and competitive price hydraulic seals
2. People can save themselves the trouble when it comes to clothes fading during washes. So it is worth the investment. DMS Seals provides professional design and production of high-grade o-ring seals
3. Every product undergoes a strict control process to ensure the best quality. We have developed solutions of the sealing of special working condition
4. The professional QC team strictly controls the quality of this product. To reduce costs with high-efficiency work is the DMS's purpose
5. The testing of the product is regularly conducted to ensure the high quality. DMS Seals implements and optimizes its quality control systems

1. Installation Recommendation

2. Application and properties

The standard combination seal is suitable for a wide range of pressure work and sliding high speed occasions. Low friction, strong wear resistance.



3. Standard materials

Sealing ring: filled PTFE

O-Ring: NBR / FKM

4. Working Conditions

Working  Conditions
Diameter Range	Pressure Range	Temperature Range	Speed	Medium
6-1600mm	0-35MPa	-30℃ +200℃	1.5 m/s	general hydraulic oil, water glycol Hydraulic oil and water emulsion type hydraulic oil.



5. Installation Dimensions

Nominal Size of Packing, and Housing dimensions				Order No.
d	D	H	L +0.2
18 20 22	27 29 31	4.3 4.3 4.3	4.5 4.5 4.5	SPN18*27*4.3 SPN20*29*4.3 SPN22*31*4.3
27 31.5 47	36 40.5 60	4.3 4.3 7.3	4.5 4.5 7.5	SPN27*36*4.3 SPN31.5*40.5*4.3 SPN47*60*7.3
53 60 65	66 73 78	7.3 7.3 7.3	7.5 7.5 7.5	SPN53*66*7.3 SPN60*73*7.3 SPN65*78*7.3
70 75 80	83 88 93	7.3 7.3 7.3	7.5 7.5 7.5	SPN70*83*7.3 SPN75*88*7.3 SPN80*93*7.3
90 100 110	103.4 113.4 123.4	7.3 7.3 7.3	7.5 7.5 7.5	SPN90*103.4*7.3 SPN100*113.4*7.3 SPN110*123.4*7.3
120 130 140	133.4 143.4 153.4	7.3 7.3 7.3	7.5 7.5 7.5	SPN120*133.4*7.3 SPN130*143.4*7.3 SPN140*153.4*7.3

Company Features
1. Dms Seals Technology Co.,limited has significant fabricating capacities for manufacturing hydraulic seals distributors .
2. Our company has recognized the importance of practicing sound environmental policies to create a healthy living condition for future generations. We also encourage our employees to embrace our company's value and work together to make it true. Get info!
