Latest hydraulic seals & supplies inc with nbr or fkm o ring to high and low speed

Company Advantages
1. DMS Seals hydraulic seals & supplies inc has to go through a series of tests. It will be tested for impact resistance, flexural strength, durability, dimensional stability, and perforation resistance.
2. The design of DMS Seals uses a holistic approach. It considers necessary design elements for high performance such as sizing, ventilation, seam technology, and body mapping technology.
3. DMS Seals is developed after taking various things into minds. The design closely relates to the mechanical structure of the human body, including arch type, foot proportion, pressure points, and weight distribution.
4. DMS Seals has to go through the necessary workmanship assessments. It will be assessed with respect to biomechanical feet comfort, stress distribution, slip resistance, and ergonomics.
5. The design of DMS Seals hydraulic seals & supplies inc is meticulous. It is carried out by our designers who assess the viability of the concepts, aesthetics, spatial layout, and safety.
6. The outstanding feature of this product lies in high performance.
7. With company philosophy of 'Quality comes first.', the product is guaranteed to meet the highest quality standards.
8. The product will be strictly tested by our experienced inspectors before shipment to ensure it meets your demand for quality.
9. It is the function of that makes hydraulic seals & supplies inc a great welcome.
10. DMS Seals has excellent service with unique design, fast delivery and abundant product lines.
11. Dms Seals Technology Co.,limited takes 'meeting customer needs and increase customer value' as the starting point for business operations.
12. Dms Seals Technology Co.,limited has always been guided by the needs of its customers.
13. When we refer to hydraulic seals & supplies inc , people all know that quality is best.
14. The service of DMS Seals is well known in hydraulic seals & supplies inc industry.

1. Installation Recommendation

2. Installation Sizes

Rod Diameter	Outer Diameter	Groove Width	Install Chamfer	Radius	Radial Clearance                S max.
d f8	D H8	L+0.2	L1	R1	10MPa	20MPa	40MPa
50-69.9	d+15.0	7.5	5.0	0.4	0.5	0.4	0.3
70-149.9	d+20.0	10.1	6.0	0.4	0.7	0.5	0.4
200-244.9	d+25.0	12.5	8.5	0.4	0.8	0.6	0.5
245-519.9	d+30.0	15.0	10.0	0.8	0.9	0.7	0.6
520-769.9	d+35.0	17.5	13.0	1.2	1.0	0.8	0.7
770-1500	d+40.0	20.0	15.0	1.2	1.0	0.8	0.7

3. Application and properties

Applied for larger diameter piston rods and heavy-duty hydraulic rod sealing system in hard working conditions. High pressure resistance, excellent resistance to gap extrusion, wear-resisting.

4. Standard materials

Sealing ring: filled PTFE

O-Ring: NBR / FKM



5. Working Conditions

Working  Conditions
Diameter Range	Pressure Range	Temperature Range	Speed	Medium
3 - 1600mm	0 - 60MPa	-30℃ +100℃	5 m/s	hydraulic oil, flame retardant liquid, water, gas

6. Installation Dimensions

Rod Dia.	Outer Dia.	Groove Width	Order No.
d f8	D H8	L+0.2
50 60 70	65 75 85	7.5 7.5 7.5	GSJ-W50*65*7.5 GSJ-W60*75*7.5 GSJ-W70*85*7.5
75 80 100	95 100 120	10 10 10	GSJ-W75*95*10 GSJ-W80*100*10 GSJ-W100*120*10
110 115 120	130 135 140	10 10 10	GSJ-W110*130*10 GSJ-W115*135*10 GSJ-W120*140*10
130 140 145	150 160 165	10 10 10	GSJ-W130*150*10 GSJ-W140*160*10 GSJ-W145*165*10
150 160 170	170 180 190	10 10 10	GSJ-W150*170*10 GSJ-W160*180*10 GSJ-W170*190*10
175 180 200	195 200 220	10 10 10	GSJ-W175*195*10 GSJ-W180*200*10 GSJ-W200*220*10
230 240 250	255 265 275	12.5 12.5 12.5	GSJ-W230*255*12.5 GSJ-W240*265*12.5 GSJ-W250*275*12.5
260 265 270	285 290 295	12.5 12.5 12.5	GSJ-W260*285*12.5 GSJ-W265*290*12.5 GSJ-W270*295*12.5
280 290 300	305 315 325	12.5 12.5 12.5	GSJ-W280*305*12.5 GSJ-W290*315*12.5 GSJ-W300*325*12.5

Company Features
1. With rich experience, Dms Seals Technology Co.,limited is unanimously acknowledged by industry people and customers. Dms Seals Technology Co.,limited is proud of its high quality hydraulic seals & supplies inc and it's warmly welcomed by customers. DMS Seals is well recognized in the hydraulic pump seals suppliers industry for its outstanding advantages of . Having been engaged in the production of seals for air cylinders for many years, Dms Seals Technology Co.,limited has large capacity and experienced team. DMS Seals mainly specializes in hydraulic seals distributors , integrating and together.
2. Dms Seals Technology Co.,limited positively innovates in piston rod seal industries. Dms Seals Technology Co.,limited has accumulated much rod seals production experience during their development. The glory of Dms Seals Technology Co.,limited can not be separated from the support and selfless dedication of its technical teams.
3. It is extremely important to Dms Seals Technology Co.,limited that our customers are not only satisfied with our products but also our service. Contact us! Dms Seals Technology Co.,limited would like to offer customers with top quality and good service. Contact us! Dms Seals Technology Co.,limited will provide our customers with best service. Contact us!

Latest hydraulic seals & supplies inc with nbr or fkm o ring to high and low speed

hydraulic seals & supplies inc

Type:
