oring seal ptfe DMS Seal Manufacturer Brand hydraulic rod seals factory

Diameter Range:

3-1600mm

Pressure Range:

0-35MPa

Temperature Range:

-30℃+200℃

Speed:

1.5m/s

Medium:

general hydraulic oil, water glycol Hydraulic oil and water emulsion type hydraulic oil.

Inquiry

Product Details

's Oil Seal Manufacturer is of exquisite workmanship, which is reflected in the details.

Company Advantages
1. To reduce costs with high-efficiency work is the DMS's purpose. With good quality and professional service, we have full confidence that DMS Seal Manufacturer will be yDMS Seal Manufacturer best partner.
2. Our products mainly include rod seals, piston seals, scraper seals, rotary seals, rubber seal products and spring seals, DMS Seal Manufacturer Is A Leading rod seals, hydraulic rod seals Company, Who Has Strong Desire To Offer High Quality Product.
3. We have developed solutions of the sealing of special working condition, DMS Seal Manufacturer Offers A Wide Range Of Specifications Of hydraulic rod seals, piston rod seal At Reasonable Price.
4. As a modern sealing technology company, DMS Seal manufacturer has a wealth of experience. DMS Seal Manufacturer has a creative and professional O Ring Manufacturers,hydraulic rod seals online design team and skilled staff.
5. The high pressure seals have strong wear resistance to hard conditions. owing to o-ring seal,rod seal catalogue in our company, our fame in pneumatic rod seals and push rod seal has been very popular.

Installation Recommendation

undefined

Application and properties

The standard combination seal is suitable for a wide range of pressure work and sliding high speed occasions. Low friction, strong wear resistance.

Standard materials

Sealing ring: filled PTFE

O-Ring: NBR / FKM

Working Conditions

Working Conditions
Diameter Range	Pressure Range	Temperature Range	Speed	Medium
3-1600mm	0-35MPa	-30℃+200℃	1.5 m/s	general hydraulic oil, water glycol Hydraulic oil and water emulsion type hydraulic oil.

Installation Dimensions

Nominal Size of Packing, and Housing dimensions				Order No.
d	D	H	L +0.2	Order No.
3 4 5	6 7 8	2.3 2.3 2.3	2.5 2.5 2.5	SPNC362.5 SPNC472.5 SPNC582.5
6 7 8	9 10 11	2.3 2.3 2.3	2.5 2.5 2.5	SPNC692.5 SPNC7102.5 SPNC8112.5
9 10 10	12 13 14	2.3 2.3 3.0	2.5 2.5 3.2	SPNC9122.5 SPNC10132.5 SPNC10143.2
11 11.2 12	15 15.2 16	3.0 3.0 3.0	3.2 3.2 3.2	SPNC11153.2 SPNC11.215.23.2 SPNC12163.2
12.5 14 15	16.5 18 19	3.0 3.0 3.0	3.2 3.2 3.2	SPNC12.516.53.2 SPNC14183.2 SPNC15193.2
16 18 20	20 22 24	3.0 3.0 3.0	3.2 3.2 3.2	SPNC16203.2 SPNC18223.2 SPNC20243.2
20 21 22	24 25 26	3.0 3.0 3.0	3.2 3.2 3.2	SPNC20243.2 SPNC21253.2 SPNC22263.2
22 22.4 24	28 28.4 30	4.4 4.4 4.4	4.7 4.7 4.7	SPNC22284.7 SPNC22.428.44.7 SPNC24304.7
25 25.5 26	31 31.5 32	4.4 4.4 4.4	4.7 4.7 4.7	SPNC25314.7 SPNC25.531.54.7 SPNC26324.7
28 29 29.5	34 35 35.5	4.4 4.4 4.4	4.7 4.7 4.7	SPNC28344.7 SPNC29354.7 SPNC29.535.54.7
30 31 31.5	36 37 37.5	4.4 4.4 4.4	4.7 4.7 4.7	SPNC30364.7 SPNC31374.7 SPNC31.537.54.7
32 34 35	38 40 41	4.4 4.4 4.4	4.7 4.7 4.7	SPNC32384.7 SPNC34404.7 SPNC35414.7
35.5 36 38	41.5 42 44	4.4 4.4 4.4	4.7 4.7 4.7	SPNC35.541.54.7 SPNC36424.7 SPNC38444.7

Installation Dimensions

Company Features
1. Dms Seals Technology Co.,limited is a professionally manufacturer that has produced world-class rod seals.
2. Dms Seals Technology Co.,limited has a strong technological capabilities.
3. DMS Seal Manufacturer emphasizes the importance of hydraulic rod seals which will attract more customers. Ask!

we welcome custom designs and ideas and is able to cater to the specific requirements. for more information, please visit the website or contact us directly with questions or inquiries.
