pfa o ring kit manufacturer with a diisocyanate or a polymeric isocyanate for sale

Company Advantages
1. The design of DMS Seal Manufacturer o ring seal supplier is of professionalism. Many factors have been taken into account, including statics, dynamics, the strength of materials, resistance to vibrations, reliability, and anti-fatigue performance.
2. DMS Seal Manufacturer o ring seal supplier has to be tested before being assembled into the final product. Its every part such as hydraulic system, engine, and other moving parts will be scrutinized and debugged by mechanical engineering technicians.
3. Through a series of tests, the quality of DMS Seal Manufacturer o ring seal supplier is guaranteed. These tests include color shading tests, symmetry checks, buckle checks, and zip tests.
4. A o ring kit manufacturer provides plenty of o ring seal supplier and o ring seal kit for users.
5. The product is extremely praised owing to their high quality and longer service life.
6. As a result of the effort, this product meets the strictest performance criteria.
7. o ring kit manufacturer has outstanding functions of o ring seal supplier.
8. Owing to the remarkable characteristics, the product is becoming increasingly widely applied in the market.
9. The product is widely used and has a high market value.
10. The market response to the product is positive, which implies that the product will be more applied in the market.
11. Products sell well in the global market, with broad market potential.

1. Installation Recommendation

2. Application and properties

Double acting seals, the sealing effect is achieved by the deformation of the section of the O-Rings, and the deformation is determined by the depth of the installation groove. Under pressure, the O-ring has a large surface tension like liquid, used for static sealing more. It is only recommended for better conditions in dynamic applications. System lubrication, pressure, temperature, sealing clearance, speed, medium and surface quality of metal parts determine the service life of O-Rings. It is not recommended if the lubrication is not sufficient during rotary motion.

3. Standard materials

NBR / FKM

4. Performance parameter

	Static Seal	Dynamic Seal
Working Pressure	No support ring, up to 20MPa; With the support ring, up to 40MPa; With special support ring, up to 200MPa.	No support ring, up to 5MPa; With the support ring, higher pressure.
Movement Speed	Maximum reciprocating speed up to 0.5m / s; maximum rotation speed up to 2.0m/s.
Temperature	NBR: -30℃ - 100℃;  FKM: -20℃ - 220℃.

5. Wire Diameter Tolerance

Wire diameter of O-Ring (mm)	Tolerance (±mm)
0-1.8	0.08
1.80-2.65	0.09
2.65-3.55	0.10
3.55-5.30	0.13
5.30-7.00	0.15
7.00-8.00	0.18
8.00-10.00	0.21
10.00-12.00	0.25



6. Inner diameter tolerance

Inner Diameter d1 mm	Tolerance ±mm	Inner Diameter d1 mm	Tolerance ±mm	Inner Diameter d1 mm	Tolerance ±mm
0.70-2.50 2.50-4.50 4.50-6.30	0.13 0.14 0.15	43.70-45.00 46.00-46.20 46.20-47.50	0.42 0.43 0.44	95.00-97.50 97.50-100.00 100.00-103.00	0.83 0.84 0.87
6.30-8.50 8.50-10.00 10.00-11.20	0.16 0.17 0.18	47.50-48.70 48.70-50.00 50.00-51.50	0.45 0.46 0.47	103.00-106.00 106.00-109.00 109.00-112.00	0.89 0.91 0.93
11.20-14.00 14.00-16.00 16.00-18.00	0.19 0.20 0.21	51.50-53.00 53.00-54.50 54.50-56.00	0.48 0.50 0.51	112.00-115.00 115.00-118.00 118.00-122.00	0.95 0.97 1.00
18.00-20.00 20.00-21.20 21.20-23.60	0.22 0.23 0.24	56.00-58.00 58.00-60.00 60.00-61.50	0.52 0.54 0.55	122.00-125.00 125.00-128.00 128.00-132.00	1.03 1.05 1.08
23.60-25.00 25.00-26.50 26.50-28.00	0.25 0.26 0.28	61.50-63.00 63.00-65.00 65.00-67.00	0.56 0.58 0.59	132.00-136.00 136.00-140.00 140.00-145-00	1.10 1.13 1.17
28.00-30.00 30.00-31.50 31.50-33.50	0.29 0.31 0.32	67.00-69.00 69.00-71.00 71.00-73.00	0.61 0.63 0.64	145.00-150.00 150.00-155.00 155.00-160.00	1.20 1.24 1.27
33.50-34.50 34.50-35.50 35.50-36.50	0.33 0.34 0.35	73.00-75.00 75.00-77.50 77.50-80.00	0.66 0.67 0.69	160.00-165.00 165.00-170.00 170.00-175.00	1.31 1.34 1.38
36.50-37.50 37.50-38.70 38.70-40.00	0.36 0.37 0.38	80.00-82.50 82.50-85.00 85.00-87.50	0.71 0.73 0.75	175.00-180.00 180.00-185.00 185.00-190.00	1.41 1.44 1.48
40.00-41.20 41.20-42.50 42.50-43.70	0.39 0.40 0.41	87.50-90.00 90.00-92.50 92.50-95.00	0.77 0.79 0.81	190.00-195.00 195.00-200.00 200.00-206.00	1.51 1.55 1.59
206.00-212.00 212.00-218.00 224.00-230.00	1.63 1.71 1.75	325.00-335.00 335.00-345.00 345.00-355.00	2.43 2.49 2.56	500.00-515.00 515.00-530.00 530.00-545.00	3.54 3.63 3.72
230.00-236.00 236.00-243.00 243.00-250.00	1.79 1.83 1.88	355.00-365.00 365.00-375.00 375.00-387.00	2.62 2.68 2.76	545.00-560.00 560.00-580.00 580.00-600.00	3.81 3.93 4.05
250.00-258.00 258.00-265.00 265.00-272.00	1.93 1.98 2.02	387.00-400.00 400.00-412.00 412.00-425.00	2.84 2.91 2.99	600.00-615.00 615.00-630.00 630.00-650.00	4.13 4.22 4.34
272.00-280.00 280.00-290.00 290.00-300.00	2.08 2.14 2.21	425.00-437.00 437.00-450.00 450.00-462.00	3.07 3.15 3.22	650.00-670.00	4.46
300.00-307.00 307.00-315.00 315.00-325.00	2.25 2.30 2.37	462.00-475.00 475.00-485.00 485.00-500.00	3.30 3.37 3.45

Company Features
1. Dms Seals Technology Co.,limited has established our o ring kit manufacturer manufacturing bases in the vast and low-cost Chinese market. Dms Seals Technology Co.,limited has become a major O Ring Manufacturer manufacturing base in China , supplying a majority of o ring seal manufacturer items to the world market. DMS Seal Manufacturer is responsible for o-ring seal business, and is the leading provider o ring seal supplier. The main business of DMS Seal Manufacturer covers the manufacturing and sales service of o ring kit manufacturer. Dms Seals Technology Co.,limited is the largest of China's domestic assembly facilities in o ring kit manufacturer field.
2. Dms Seals Technology Co.,limited has developed a variety of high-tech o ring kit manufacturer in response to the needs of the market. The production process of o ring kit manufacturer is completed in our advanced equipment. We've got dozens of patents for our technology to produce o ring kit manufacturer.
3. DMS Seal Manufacturer aims to help you realize your own values and dreams. Get more info! We always place high quality of o ring kit manufacturer in first place. Get more info! Dms Seals Technology Co.,limited is committed to technological innovation, ensure the quality of our products. Get more info!
