Professional dowty seal for sale for threaded pipe fittings and plug sealing

Company Advantages
1. The design team has been researching DMS Seals with innovations, keeping up with the trends.
2. is built using standard materials procured from trusted vendors of the market.
3. The production speed of DMS Seals is guaranteed by highly advanced production technology.
4. The product features the desired safety. Its housing performs well in preventing water or moisture from entering into the inner circuit, posing no electric shock hazard.
5. It will not fade or begin to look ratty after prolonged exposure to the sun or being washed for a certain number of times.
6. This product is safe in use. It has been designed with 10 safety mechanisms, such as overload and overvoltage protection to guard against any accidents.
7. The product can create a large profit margin for customers.
8. This product will have a high retention of market share in the next few years.
9. Dms Seals Technology Co.,limited wants to provide the good products with low price and high quality.
10. Dms Seals Technology Co.,limited's company culture is to produce good products and provide professional services.
11. The actual application prospects of this product are broad.

1. Applicability of the Bonded Seal Washer

The BS/A bonded seals (automatic core-positioning) are applicable to threaded pipe fittings and plug sealing in Metric System, the Britain System and BSP. The location processing of sealing groove is not specially required, so it is ideal fittings for fast and automatic installation. Its service temperature is -30℃~100℃, working pressure less than 39.2MPa.

2. Figure

2. GM500 Self-centering range metric dimensions

Metric Thread size	Inside Diameter	Outside Diameter	Metal thickness	Metal washer ID	ID between self centering
	C	A	E	B	F
PPM6	6,50	10,00	1,00	8,00	5,60
PPM8	8,5	14,00	1,00	10,40	6,40
PPM10	10,50	16,00	2,00	12,40	8,05
PPM12	12,50	18,00	1,50	14,10	9,73
PPM14	14,5	20,00	2,00	16,40	11,38
PPM16	16,5	22,00	2,00	18,40	13,41
PPM18	18,5	25,00	2,00	20,40	14,76
PPM20	20,5	28,00	2,00	22,50	16,76
PPM22	22,5	30,00	2,00	24,40	18,74
PPM24	24,5	32,00	2,00	26,40	20,11
PPM27	27,2	35,00	2,00	29,40	23,30
PPM30	30,7	38,00	2,00	32,40	25,70
PPM33	33,5	42,00	2,00	35,40	28,70
PPM36	36.7	46,00	2,00	38,70	31.1
PPM39	41.9	51,00	2,00	40,00	34.1
PPM42	42.7	53,00	2,00	45,70	38.7
PPM48	48.7	60,00	2,00	51,70	43.7
PPM52	52.9	66,00	2,00	56,40	46
PPM60	60.9	75,00	2,00	63,00	-

3. GM500 Self-centering range inch dimensions, BSP

BSP thread size	Inside Diameter	Outside Diameter	Metal thickness	Metal washer ID	ID between self centering
	C	A	E	B	F
1/8 BSP	10,37	15,88	2,00	11,84	8,26
1/4 BSP	13,74	20,57	2,00	15,21	11,18
3/8 BSP	17,28	23,80	2,00	18,75	14,76
1/2 BSP	21,54	28,58	2,50	23,01	18,24
3/4 BSP	27,05	34,93	2,50	28,53	23,83
1 BSP	33,89	42,80	3,20	36,88	29,92
1 1/4 BSP	42,93	52,38	3,20	45,93	38,45
1 1/2 BSP	48,44	58,60	3,20	51,39	44,45
2 BSP	60,58	73,03	3,20	63,63	56,26



Best quality bonded seal wholesale, welcome to contact the leading bonded seal rings and bonded washers suppliers.

Company Features
1. Dms Seals Technology Co.,limited has defeated many peer manufacturers in China market when it comes to dowty seal development and production. For years of development, Dms Seals Technology Co.,limited has become one of the most trustworthy manufacturers of dowty sealing washer and is broadly recognized in the industry. Since establishment, Dms Seals Technology Co.,limited has been focusing on manufacturing dowty washer sizes . We are one of the major manufacturers and suppliers in the market. Dms Seals Technology Co.,limited is a well-established manufacturing company. Today we are a leader in the design and production of in China.
2. We've been focusing on manufacturing high quality dowty o ring sizes for domestic and abroad customers. Strict tests have been conducted for stainless steel dowty washers . The quality of our bonded seal washer sizes still keeps unsurpassed in China. we have successfully developed a variety of m6 dowty washer series. All our dowty ring have conducted strict tests.
3. Our quality guideline is dowty hydraulic pump seal kit which helps promote our reputation. Call! Through open collaboration with , we create lasting value for our customers. Call! Not one of the exquisite bonded seal kit and excellent service can be dispensed with if DMS Seals aims to be the leading supplier. Call! Dms Seals Technology Co.,limited responds to customer needs, inspiring new product and service ideas. Call! Exploring the value of dowty seal pressure rating with full gratitude and reverence is of great importance for DMS Seals at present. Call!
