Quality DMS Seal Manufacturer Brand oring rod seals

Diameter Range:

6-1600mm

Pressure Range:

0-35MPa

Temperature Range:

-30℃ +200℃

Speed:

1.5 m/s

Medium:

general hydraulic oil, water glycol Hydraulic oil and water emulsion type hydraulic oil.

Inquiry

Enterprise Strength

has a professional R&D team and a high-quality production team, who are the solid foundation of corporate development. The team members are experienced and innovative, for they are engaged in production for many years.
wholeheartedly provides intimate and reasonable services for customers.
In the future, will always adhere to the business philosophy of 'survive with quality, develop with reputation'. We strive to transform the development mode and deepen the optimized combination of the supply chain, value chain, and management chain. Moreover, we implement the scientific brand development strategy to create the first-class brand within the industry. Our goal is to become a leader in the domestic market.
was founded in . Having accumulated experience for years, we are now a leading enterprise in the industry.
's sales outlets are all over the country, and the products are sold to major domestic markets. At the same time, the business personnel is actively exploring overseas markets.

Company Advantages
1. DMS Seal Manufacturer rod seals is made by raw materials which meet the quality standards. DMS o-ring seal has advanced machines and equipment for its production
2. Widely used for hydraulic rod seals, these hydraulic rod seals are known for offering maximum satisfaction to the clients. DMS Seals' production equipment and test equipment are on the leading level in the industry
3. DMS Seal Manufacturer is proud of building friendly relationships with new and existing business partners. DMS Seals takes the lead in grasping the development trend of the industry

Installation Recommendation

undefined

Application and properties

The standard combination seal is suitable for a wide range of pressure work and sliding high speed occasions. Low friction, strong wear resistance.

Standard materials

Sealing ring: filled PTFE

O-ring: NBR / FKM

Working Conditions

Working Conditions
Diameter Range	Pressure Range	Temperature Range	Speed	Medium
6-1600mm	0-35MPa	-30℃ +200℃	1.5 m/s	general hydraulic oil, water glycol Hydraulic oil and water emulsion type hydraulic oil.

Installation Dimensions

Nominal Size of Packing, and Housing dimensions				Order No.
d	D	H	L +0.2	Order No.
18 20 22	27 29 31	4.3 4.3 4.3	4.5 4.5 4.5	SPN18274.3 SPN20294.3 SPN22314.3
27 31.5 47	36 40.5 60	4.3 4.3 7.3	4.5 4.5 7.5	SPN27364.3 SPN31.540.54.3 SPN47607.3
53 60 65	66 73 78	7.3 7.3 7.3	7.5 7.5 7.5	SPN53667.3 SPN60737.3 SPN65787.3
70 75 80	83 88 93	7.3 7.3 7.3	7.5 7.5 7.5	SPN70837.3 SPN75887.3 SPN80937.3
90 100 110	103.4 113.4 123.4	7.3 7.3 7.3	7.5 7.5 7.5	SPN90103.47.3 SPN100113.47.3 SPN110123.47.3
120 130 140	133.4 143.4 153.4	7.3 7.3 7.3	7.5 7.5 7.5	SPN120133.47.3 SPN130143.47.3 SPN140153.47.3
