rod seals with nbr or pu for sale

Company Advantages
1. DMS Seal Manufacturer rod seals is designed with reasonable and optimized dehydrating structure by our professional designers who have many years of experience in creating different types of food dehydrators for various applications.
2. DMS Seal Manufacturer push rod seal is strictly inspected. It is carried out by our QC team who checks its flammability, tension, corrosion resistance, and other performance characteristics.
3. The production of DMS Seal Manufacturer push rod seal consists of two major steps. The first step is the extraction of raw materials; the second step is the grinding into pre-treated building materials.
4. DMS Seal Manufacturer push rod seal is developed and produced complying with concepts such as comfort, breathability, wrinkle resistance, and hygroscopicity, to meet the highest textile standards.
5. rod seals are recognized for their peculiarities for push rod seal.
6. The rod seals is very convenient and easy to handle for its high performance.
7. Featuring push rod seal, rod seals is suitable for hydraulic rod seals .
8. Being qualified with push rod seal makes rod seals consequent to be the fashion trend.
9. The product has been considered to have a wide development prospect.
10. The product is increasingly accepted by customers in the industry.
11. This product has a longer lifespan than other similar products for its stable performance.
12. The product has received many praises with its broad application prospects.
13. The product is popular in both the domestic and international market for its broad application prospects.

1. Installation Recommendation

2. Installation Sizes

Rod Diameter	Outer Diameter	Groove Width	Install Chamfer	Radius	Radial Clearance                S max.
d f8	D H8	L+0.2	L1	R1	10MPa	20MPa	40MPa
50-69.9	d+15.0	7.5	5.0	0.4	0.5	0.4	0.3
70-149.9	d+20.0	10.1	6.0	0.4	0.7	0.5	0.4
200-244.9	d+25.0	12.5	8.5	0.4	0.8	0.6	0.5
245-519.9	d+30.0	15.0	10.0	0.8	0.9	0.7	0.6
520-769.9	d+35.0	17.5	13.0	1.2	1.0	0.8	0.7
770-1500	d+40.0	20.0	15.0	1.2	1.0	0.8	0.7

3. Application and properties

Applied for larger diameter piston rods and heavy-duty hydraulic rod sealing system in hard working conditions. High pressure resistance, excellent resistance to gap extrusion, wear-resisting.

4. Standard materials

Sealing ring: filled PTFE

O-Ring: NBR / FKM



5. Working Conditions

Working  Conditions
Diameter Range	Pressure Range	Temperature Range	Speed	Medium
3 - 1600mm	0 - 60MPa	-30℃ +100℃	5 m/s	hydraulic oil, flame retardant liquid, water, gas

6. Installation Dimensions

Rod Dia.	Outer Dia.	Groove Width	Order No.
d f8	D H8	L+0.2
50 60 70	65 75 85	7.5 7.5 7.5	GSJ-W50*65*7.5 GSJ-W60*75*7.5 GSJ-W70*85*7.5
75 80 100	95 100 120	10 10 10	GSJ-W75*95*10 GSJ-W80*100*10 GSJ-W100*120*10
110 115 120	130 135 140	10 10 10	GSJ-W110*130*10 GSJ-W115*135*10 GSJ-W120*140*10
130 140 145	150 160 165	10 10 10	GSJ-W130*150*10 GSJ-W140*160*10 GSJ-W145*165*10
150 160 170	170 180 190	10 10 10	GSJ-W150*170*10 GSJ-W160*180*10 GSJ-W170*190*10
175 180 200	195 200 220	10 10 10	GSJ-W175*195*10 GSJ-W180*200*10 GSJ-W200*220*10
230 240 250	255 265 275	12.5 12.5 12.5	GSJ-W230*255*12.5 GSJ-W240*265*12.5 GSJ-W250*275*12.5
260 265 270	285 290 295	12.5 12.5 12.5	GSJ-W260*285*12.5 GSJ-W265*290*12.5 GSJ-W270*295*12.5
280 290 300	305 315 325	12.5 12.5 12.5	GSJ-W280*305*12.5 GSJ-W290*315*12.5 GSJ-W300*325*12.5

Company Features
1. Dms Seals Technology Co.,limited has been a trusted company in the Chinese market. We never fail to deliver high quality push rod seal. Dms Seals Technology Co.,limited is a trustworthy manufacturer of rod seals . With years of development, we have been successfully accepted by the industry. Dms Seals Technology Co.,limited is recognized as one of the most reputable manufacturers in China. We specialize in the development, design, and production of hydraulic rod seals . Dms Seals Technology Co.,limited has a proud and extensive product manufacturing and developing history. Currently, our main business is providing pneumatic rod seals . With years of evolvement, Dms Seals Technology Co.,limited has been recognized as an expert in developing, designing, and manufacturing O Ring Manufacturers .
2. In view of the interests of customers, DMS Seal Manufacturer is able to ensure the durability of o-ring seal. The technicians who have been experienced in producing hydraulic rod seals are well-equipped in our factory. There were massive expansions on key production lines to keep the supply flowing of Dms Seals Technology Co.,limited. Our advanced technology not only assures quality for rod seals but also cut cost for it.
3. To provide the superb rod seals and service experiences for our users is Dms Seals Technology Co.,limited's vision. Call now! It is very urgent for DMS Seal Manufacturer to adapt to the rapid development of globalization and information technology. Call now! For the goal of being a pioneer in rod seals industry, DMS Seal Manufacturer strives to fulfill the tenet of quality first and customer foremost. Call now!
