DMS SEALS TECHNOLOGY CO.,LIMITED
The Professional Sealing Solution Supplier(O Ring Suppliers & Oil Seal Manufacturers).
DMS Seals - Hydraulic Seals and Oil Ring Seals Manufacturer & Supplier
seal ptfe OEM scraper seals DMS Seal Manufacturer
- Dms Seals has high-quality teams that understand technology and knows well about management, which lays a solid foundation for the development and growth.
- Dms Seals always keeps in mind the principle that 'there are no small problems of customers'. We are committed to providing quality and considerate services for customers.
- Dms Seals will adhere to the enterprise spirit which is to be people-oriented, sincere and trustworthy. We follow the business concept of 'talent is the foundation, sci-tech is the guide, management is the basis, quality is the center'. With a focus on the development tendency of domestic and foreign markets, we strive to achieve product differentiation depending on technological innovation. Our goal is to continuously provide more quality products and services for consumers.
- After years of steady development, Dms Seals accumulates rich experience in R&D and production. Moreover, we are familiar with the latest needs of domestic and foreign markets, and can meet the needs of customers.
- O-ring Seal's sales network covers all major domestic cities and other countries and regions, such as America, Australia, and Southeast Asia.
1. The quality of this product is guaranteed with the assistance of our vast expertise and immerse knowledge in this domain. DMS Seal manufacturer was established in 2008 and now has more than 10 years professional experience
2. Our experienced team pays much more attention to the crafts design of hydraulic wiper seals. As a modern sealing technology company, DMS Seal manufacturer has a wealth of experience
3. scraper seals has passed all relative quality certificates. DMS Seal manufacturer is a technology enterprise which specialized in the R&D and production of seals
4. hydraulic wiper seals advances with time. High-end talents and advanced technology have enabled DMS o-ring seal quality to reach the industry's leading level
Rod Diameter d f8/h9 | Groove Diameter | Groove Width | Step Diameter | Radius | Step Width | |
Standard Application | Suitable | D H9 | L1+0.2 | D1±0.1 | R | a |
140.0-229.9 | 100.0-450.0 | d+22.2 | 6.3 | d+10.7 | 1.2 | 4.2 |
230.0-299.9 | 220.0-450.0 | d+24.2 | 6.3 | d+10.7 | 1.2 | 4.2 |
300.0-629.9 | 250.0-650.0 | d+33.0 | 8.1 | d+15.1 | 1.2 | 6.3 |
630.0-999.9 | 550.0-999.9 | d+36.5 | 9.5 | d+15.1 | 2.0 | 6.3 |
Application and properties
Applicable to agricultural hydraulic press, injection molding machine, metallurgical equipment, etc. Consisting of a sealing ring and two O-Rings as preload element, good dust scraping effect, low friction, no stick slip phenomenon, good ability of adjustment and positioning, especially for large diameter piston rods.
Standard materials
Sealing ring: filled PTFE / PU
O-Ring: NBR / FKM
Working Conditions | ||||
Diameter Range | Pressure Range | Temperature Range | Speed | Medium |
3-1600mm | -30℃+200℃ | 5 m/s | hydraulic oil, flame retardant liquid, water and others | |
d f8 | D H9 | H | L1+0.2 | L1 | Order No. |
100 | 122.2 | 13.5 | 6.3 | 4.2 | DPT2-100*122.2*6.3 |
130 | 152.2 | 13.5 | 6.3 | 4.2 | DPT2-130*152.2*6.3 |
160 | 182.2 | 13.5 | 6.3 | 4.2 | DPT2-160*182.2*6.3 |
190 | 212.2 | 13.5 | 6.3 | 4.2 | DPT2-190*212.2*6.3 |
220 | 242.2 | 13.5 | 6.3 | 4.2 | DPT2-220*242.2*6.3 |
250 | 272.2 | 13.5 | 6.3 | 4.2 | DPT2-250*272.2*6.3 |
275 | 297.2 | 13.5 | 6.3 | 4.2 | DPT2-275*297.2*6.3 |
295 | 317.2 | 13.5 | 6.3 | 4.2 | DPT2-295*317.2*6.3 |
340 | 373 | 18.4 | 8.1 | 6.3 | DPT2-340*373*8.1 |
Company Features
1. For many consumers in many countries, DMS Seal Manufacturer is the number one brand in the field.
2. Our production technology for hydraulic wiper seals is in a leading position in the world and has a broad prospect.
3. Dms Seals Technology Co.,limited tries to structure wiper seal design as its service ideology. Inquiry!
