spring energized seals solutions for reciprocating piston rod or piston single acting seal DMS Seal Manufacturer

Company Advantages
1. DMS Seal Manufacturer spring energized seals can be customized through manufacturing facilities.
2. DMS Seal Manufacturer spring energized seals is practically designed and beautifully manufactured.
3. DMS Seal Manufacturerspring energized seals is of a design that is both creative and functional.
4. The value of environmental protection offered by the spring energized seals has been widely favored by customers.
5. DMS Seal Manufacturer spring loaded seal offers desirable design and appealing appearance.
6. This product has been well received by customers for its high performance and durability.
7. Our quality controllers are responsible for continuous small changes to keep production within the specified parameters and to ensure product quality.
8. The product has high performance reliability and relatively long service life.
9. This product provides good reliability and excellent performance at low cost.
10. It is recognized by the majority of users in different occasions.
11. Dms Seals Technology Co.,limited's design team will analyze the feasibility and cost of your customized project.
12. Dms Seals Technology Co.,limited has repeatedly experience of spring energized seals in the industry.
13. The product is considered to have good economic benefits and vast market potentials.

1. Application and properties

Suitable for reciprocating piston rod or piston single acting seal, the working pressure has a wide range of adaptability, and the pressure capacity can be enhanced by increasing the tail length size or increasing the check ring.

Small friction coefficient, The contact pressure between the mating surface and the mating surface is low, and the friction between the work face and the mating surface is the smallest in all seal types. with or without lubrication can work, wear resistance, long service life.

The working medium of the sealing sleeve has wide adaptability, and the other chemicals are not reacted except soluble alkali metal, high temperature fluorine gas and three fluoride chloride.

The working temperature range is wide, and can be used for -200 ℃ to +250 ℃.

It can be used for very high speed, very low speed, micro-stroke and other special conditions.

Suitable for aviation, military and industrial sealing groove size, The standard installation groove is the same size as the standard O ring, and the size is small. It can be designed as non standard parts to meet the sealing requirements of any size groove. The groove is open or semi open.

It can be used in rotary sealing. It can adapt to large eccentricity and beating.

2. Standard materials

Sealing sleeve: PTFE

Spring: Stainless steel 304, 316

3. Working Conditions

Working  Conditions
Diameter Range	Pressure Range	Temperature Range ℃	Speed	Medium
3 - 1600mm	0 - 20MPa	-200 ~ +250	5 m/s	High and low temperature oil and water and other fluids.

4. Installation Sizes

Back pressure surfaceR1=0.1 ~ 0.2, tank bottom R2=0.3 ~ 0.5, Import lengthC=(0.7 ~ 1.0)L.

Rod Diameter	Groove Width	Groove Diameter	Radial Clearance
d	L	D	e
2 ~ 10	2.5	d+3.0	0.05
10 ~ 22	3.2	d+4.0	0.065
22 ~ 52	4.7	d+6.0	0.075
48 ~ 150	7.5	d+10.0	0.09
150 ~ 400	11.0	d+15.0	0.10

5. Matters needing attention

Ⅰ, The installation groove must be open or semi open, and it is recommended to be open.

Ⅱ, If the seal is for the rotating shaft, it is recommended that the surface hardness of the shaft should be no less than HRC40.

Ⅲ，Considering the adaptability of the working medium, the adaptability of the jacket and spring should be taken into account.

Ⅳ, It is better to install an anti fouling ring or a antifouling guide ring in the notch direction in front of the seal.
