Top hydraulic cylinder gaskets with nbr or fkm o ring for sale

Company Advantages
1. DMS Seal Manufacturer hydraulic cylinder gaskets is developed and manufactured using the latest technology materials. Seal we produced has applications in a wide range of fields
2. With high style inclusiveness, the product can be placed in various room styles, including residential houses, hotels, and commercial offices. DMS Seals' production equipment and test equipment are on the leading level in the industry
3. hydraulic cylinder gaskets can be in normal work status at day and night. The R&D teams have the ability to design and develop seals for various of complicated working condition of sealing system

1. Installation Recommendation

2. Installation Sizes

Rod Diameter d e8	Groove Diameter D H9	Groove Width L D10	H
20-56	d+10	16	15
57-140	d+13	16	15
＞140	d+15	16	15

3. Application and properties

Suitable for tandem type internal sealing, and can be used as fluid sealing and dust sealing simultaneously. Excellent sealing effect can be achieved in case of no pressure. Easy installation, wear-resisting, anti extrusion, low friction, non stick slip phenomenon.

4. Standard materials

Sealing ring: filled PTFE

O-Ring: NBR / PU

5. Working Conditions

Working  Conditions
Diameter Range	Pressure Range	Temperature Range	Speed	Medium
3 - 1600mm	0 - 25MPa	-30℃ + 100℃	1 m/s	hydraulic oil, flame retardant liquid, water, gas

6. Installation Dimensions

d e8	D1 H9	H	L D10	e	Order No.
50 55 56	60 65 66	15 15 15	16 16 16	6 6 6	MDI50*60*15 MDI55*65*15 MDI56*66*15
60 63 65	73 76 78	15 15 15	16 16 16	7 7 7	MDI60*73*15 MDI63*76*15 MDI65*78*15
70 72 75	83 85 88	15 15 15	16 16 16	7 7 7	MDI70*83*15 MDI72*85*15 MDI75*88*15
80 85 90	93 98 103	15 15 15	16 16 16	7 7 7	MDI80*93*15 MDI85*98*15 MDI90*103*15
95 100 105	108 113 118	15 15 15	16 16 16	7 7 10	MDI95*108*15 MDI100*113*15 MDI105*118*15
110 110 115	120 123 128	15 15 15	16 16 16	10 10 10	MDI110*120*15 MDI110*123*15 MDI115*128*15
120 125 130	133 138 143	15 15 15	16 16 16	10 10 10	MDI120*133*15 MDI125*138*15 MDI130*143*15
140 150 150	153 162 165	15 15 15	16 16 16	10 10 10	MDI140*153*15 MDI150*162*15 MDI150*165*15
160 165 170	175 180 185	15 15 15	16 16 16	10 10 10	MDI160*175*15 MDI165*180*15 MDI170*185*15
180 185 190	195 200 205	15 15 15	16 16 16	10 10 10	MDI180*195*15 MDI185*200*15 MDI190*205*15

Company Features
1. Dms Seals Technology Co.,limited is a mature manufacturing company. Today we are the leader in designing and productioning in China. Dms Seals Technology Co.,limited insists on continuous investment in R&D of products in order to enhance its technological advantages.
2. Dms Seals Technology Co.,limited's technology is at the domestic advanced level.
3. DMS Seal Manufacturer has been insisting on independent innovation technology to establish its own core business. By establishing collaboration with our suppliers to reduce waste, increase resource productivity, and optimize material usage, we are moving toward more sustainable development.
