Top hydraulic packing kits Suppliers for pneumatic equipment

Company Advantages
1. DMS Seal Manufacturer has gone through a series of production processes. They involve CAD/CAM design, prototyping, milling, turning, welding, painting, and commissioning.
2. The fabric of DMS Seal Manufacturer hydraulic packing kits comes from reliable suppliers who have signed contracts with us for many years to ensure the best fabric quality.
3. DMS Seal Manufacturer hydraulic packing kits is made of materials that are rigorously selected to meet the furniture processing requirement. Several factors will be considered when selecting materials, such as processability, texture, appearance quality, strength, as well as economical efficiency.
4. Its quality is guaranteed by a team of people who are dedicated to improving the whole the quality control system.
5. The product not only has passed the domestic quality standards but also has been approved by many international certificates.
6. To ensure the quality of this product, DMS Seal Manufacturer has guaranteed each phrase in a good condition.
7. With the world’s advanced automatic production line and computer detection equipment, the quality of this product is guaranteed.
8. The quality is the key to the victory of this product in market competition.
9. This mattress can provide some relief for health issues like arthritis, fibromyalgia, rheumatism, sciatica, and tingling of the hands and feet.
10. The heavy-duty work which man can never do can be done by this product. With the aid of this product, such jobs can be done easily.
11. Its benefits of reducing costs and maximizing profits have encouraged many manufacturers in the industry to adopt this product in production.
12. With the regular maintenance, the product is able to work as efficiently as possible and could last for many years.

1. Installation Recommendation

2. Installation Sizes

Bore Diameter                         DN H9			Groove Diameter	Groove Width	Radius	Radial Clearance                S max.			O-Ring Cross-Section
Standard Application	Light Application	Heavy Duty Application	d1 h9	L1+0.2	R1	10MPa	20MPa	40MPa	d2
8-14.9	15-39.9	-	DN-4.9	2.2	0.4	0.3	0.20	0.15	1.78
15-39.9	40-79.9	-	DN-7.5	3.2	0.6	0.4	0.25	0.15	2.62
40-79.9	80-132.9	15-39.9	DN-11.0	4.2	1.0	0.4	0.25	0.20	3.53
80-132.9	133-329.9	40-79.9	DN-15.5	6.3	1.3	0.5	0.30	0.20	5.33
133-329.9	330-699.9	80-132.9	DN-21.0	8.1	1.8	0.6	0.35	0.25	7.00
330-669.9	670-99.9	133-329.9	DN-24.5	8.1	1.8	0.6	0.35	0.25	7.00
670-999.9	≥1000	330-669.9	DN-28.0	9.5	2.5	0.7	0.50	0.30	8.40
≥1000	≥1000	≥1000	DN-38.0	13.8	3.0	1.0	0.70	0.60	12.00

3. Application and properties

Standard double acting seal. Suitable for reciprocating motion, allowing larger extrusion clearances, has wide application. Dynamic and static sealing property are excellent, be able to work in dusty condition. Low friction, simple groove, strong adaptability to work conditions.

4. Standard materials

Sealing ring: filled PTFE

O-Ring: NBR / FKM

5. Working Conditions

Working  Conditions
Diameter Range	Pressure Range	Temperature Range	Speed	Medium
3 - 1600mm	0 - 60MPa	-45℃ +200℃	15 m/s	hydraulic oil, flame retardant liquid, water and others

6. Installation Dimensions

Bore Dia.	Groove Dia.	Groove Width	Order No.	O-Ring Dimensions
DN H9	d1 h9	L1+0.2
8 10 12	3.1 5.1 7.1	2.2 2.2 2.2	GSF8*3.1*2.2 GSF10*5.1*2.2 GSF12*7.1*2.2	2.90*1.78 4.80*1.8 6.70*1.8
14 15 15	9.1 10.1 7.5	2.2 2.2 3.2	GSF14*9.1*2.2 GSF15*10.1*2.2 GSF15*7.5*3.2	8.75*1.8 7.59*2.62 8.75*1.8
16 16 18	11.1 8.5 13.1	2.2 3.2 2.2	GSF16*11.1*2.2 GSF16*8.5*3.2 GSF18*13.1*2.2	10.82*1.78 7.59*2.62 12.42*1.78
18 20 20	10.5 15.1 12.5	3.2 2.2 3.2	GSF18*10.5*3.2 GSF20*15.1*2.2 GSF20*12.5*3.2	9.19*2.62 14.00*1.78 12.37*2.62
24 24 25	19.1 16.5 17.5	2.2 3.2 3.2	GSF24*19.1*2.2 GSF24*16.5*3.2 GSF25*17.5*3.2	18.77*1.78 15.54*2.62 17.12*2.62
25 28 28	14 20.5 17	4.2 3.2 4.2	GSF25*14*4.2 GSF28*20.5*3.2 GSF28*17*4.2	13.87*3.53 20.29*2.62 15.47*3.53
30 30 32	22.5 19 24.5	3.2 4.2 3.2	GSF30*22.5*3.2 GSF30*19*4.2 GSF32*24.5*3.2	21.89*2.62 26.70*1.78 23.47*2.62

Company Features
1. Dms Seals Technology Co.,limited designs and manufactures high quality and reliable with the main focus on realizing customer needs. With a high reputation in the domestic markets, Dms Seals Technology Co.,limited is regarded as a strong competitor in the manufacturing of . Dms Seals Technology Co.,limited keeps at the forefront of the competition in the developing and manufacturing of for years. Dms Seals Technology Co.,limited has years of experience in patent design, innovative ideas, exceptional quality, and competitive price of . Dms Seals Technology Co.,limited has developed, designed various products involving . We are notable for our strong ability in developing and manufacturing.
2. The DMS Seal Manufacturer's commitment to hydraulic packing kits quality improvement and new product development is unwavering. DMS Seal Manufacturer combines the best technology with outstanding people to deliver lasting performance. DMS Seal Manufacturer's quality is gradually being recognized by the majority of user. Applying the best technology to the hydraulic seal kits suppliers has become a good idea.
3. DMS Seal Manufacturer always stress the importance of high quality service. Please contact. 'High Reputation ' is the constant objective of Dms Seals Technology Co.,limited. Please contact. Dms Seals Technology Co.,limited will always adhere to the spirit of 'practical , effective , exploitative'. Please contact.
