Top piston seal price for pressure work and sliding high speed occasions

Company Advantages
1. DMS Seals has passed the required tests. These tests cover materials insulation testing, vibration testing, flame retardant testing, water ingress (IP) testing, etc.
2. DMS Seals features a reasonable and practical design. It is created by the designers who have taken radiation level, anti-jamming capability, and electromagnetic compatibility into consideration.
3. DMS Seals is of flexible design. It is created by our designers who understand elements of design and use them in different ways to produce different kinds of art/objects and visual effects.
4. DMS Seals has gone through a comprehensive range of tests. They may include life cycle testing, shock & vibration testing, temperature testing, humidity testing, and combined environmental testing.
5. DMS Seals is the outcome of high quality. It's constantly tested in terms of its performance in the water, anti-aging, and UV resistant capacity.
6. This product touches very smooth and cool. The glaze is evenly and shapely done after low-temperature firing, cooling, and high-temperature firing processes.
7. This product features dimensional stability. Its every detail is tested by high-precision instruments to ensure that the dimensional accuracy is within the controllable range.
8. The product is highly chemical resistant. It is treated with a protective chemical coating or with protective paintwork to prevent corrosion.
9. The product has enough hardness. It has passed the hardness testing that can resist shape changes such as indentation and scratch.
10. The product will not accumulate too much heat. Its substrate used has improved heat dissipation, which greatly lowers the operating temperature.
11. This product can fit the natural shape of people's feet. So people who use this product will not easily have a feet pain problem.
12. This product is an essential investment for every household. It is one of the necessary commodities for various domicile and commercial purposes.
13. People who suffer from allergies and various skin conditions will probably come notice that this product will not agitate their symptoms.
14. Its enough elasticity creates a comfortable fit for all-day wear. The product allows easy movement such as stretch, walk, squat, crawl, and so on.
15. When it comes to furnishing the room, this product is the preferred choice that is both stylish and functional that is needed for most people.

1. Installation Recommendation

2. Installation Sizes

Rod Diameter d e8	Groove Diameter D H9	Groove Width L D10	H
20-56	d+10	16	15
57-140	d+13	16	15
＞140	d+15	16	15

3. Application and properties

Suitable for tandem type internal sealing, and can be used as fluid sealing and dust sealing simultaneously. Excellent sealing effect can be achieved in case of no pressure. Easy installation, wear-resisting, anti extrusion, low friction, non stick slip phenomenon.

4. Standard materials

Sealing ring: filled PTFE

O-Ring: NBR / PU

5. Working Conditions

Working  Conditions
Diameter Range	Pressure Range	Temperature Range	Speed	Medium
3 - 1600mm	0 - 25MPa	-30℃ + 100℃	1 m/s	hydraulic oil, flame retardant liquid, water, gas

6. Installation Dimensions

d e8	D1 H9	H	L D10	e	Order No.
50 55 56	60 65 66	15 15 15	16 16 16	6 6 6	MDI50*60*15 MDI55*65*15 MDI56*66*15
60 63 65	73 76 78	15 15 15	16 16 16	7 7 7	MDI60*73*15 MDI63*76*15 MDI65*78*15
70 72 75	83 85 88	15 15 15	16 16 16	7 7 7	MDI70*83*15 MDI72*85*15 MDI75*88*15
80 85 90	93 98 103	15 15 15	16 16 16	7 7 7	MDI80*93*15 MDI85*98*15 MDI90*103*15
95 100 105	108 113 118	15 15 15	16 16 16	7 7 10	MDI95*108*15 MDI100*113*15 MDI105*118*15
110 110 115	120 123 128	15 15 15	16 16 16	10 10 10	MDI110*120*15 MDI110*123*15 MDI115*128*15
120 125 130	133 138 143	15 15 15	16 16 16	10 10 10	MDI120*133*15 MDI125*138*15 MDI130*143*15
140 150 150	153 162 165	15 15 15	16 16 16	10 10 10	MDI140*153*15 MDI150*162*15 MDI150*165*15
160 165 170	175 180 185	15 15 15	16 16 16	10 10 10	MDI160*175*15 MDI165*180*15 MDI170*185*15
180 185 190	195 200 205	15 15 15	16 16 16	10 10 10	MDI180*195*15 MDI185*200*15 MDI190*205*15

Company Features
1. Dms Seals Technology Co.,limited is the first large manufacturer in China specializing in producing piston seal . Dms Seals Technology Co.,limited has made an overall image of a new and high-tech pneumatic cylinder rod seal enterprise. Dms Seals Technology Co.,limited gets a number of branch offices located in overseas countries. Through relentless efforts, DMS Seals has fully achieved the construction of hydraulic packing kits which covers a wide range of . Dms Seals Technology Co.,limited is a strong hydraulic cylinder piston rings enterprise full of competition.
2. Staff working in Dms Seals Technology Co.,limited are all well-trained. Almost all technician talent for the industry of pneumatic rod seals work in our Dms Seals Technology Co.,limited. hydraulic swivel seals is assembled by our highly skilled professionals.
3. With the spirit of "innovation and progress", we will keep moving forward steadily. We will focus on market trends and buyers tendency, so as to come up with creative product designs. We continuously enhance our practices in sustainability. We reduce CO2 emissions and the use of natural resources as well as improve energy and water efficiency. We assume our social responsibility in protecting consumers' rights and interests. We pledge not to produce any harmful, toxic, and health-dangering products. We have a clear commitment to sustainable development. We work hard to reduce the production waste and pollution in the course of our operations.
