Wholesale bucket cylinder seal kit supplier for light and medium hydraulic systems

Company Advantages
1. DMS Seals complies with all kinds of certifications. They may include CE certificate, UL certificate, CCC certificate, and CB certificate.
2. DMS Seals is manufactured using state-of-the-art processing machines. They include CNC cutting&drilling machines, 3D imaging machines, and computer-controlled laser engraving machines.
3. The design of DMS Seals is of innovation. It is carried out by our designers who keep their eyes on current furniture market styles or forms.
4. The quality of DMS Seals will be certified by professional inspection methods, including visual inspection, metallographic examination, and non-destructive inspection.
5. This product features physiological comfort. Its material constituents (fiber, yarn and fabric) and constructional properties all contribute to this feature.
6. This product can maintain its clean appearance. Its antistatic fabrics help keep particles away from it and make it not easily get dusty.
7. This product is endowed with aesthetics. Simultaneous creation of the textile design aesthetics and garment silhouette & structure makes it visually appealing.
8. This product is widely used by people from all walks of life.
9. This product has attracted a lot of attention and will be used more by people in various fields.
10. This product offers superior performance for every application.

1. Installation Recommendation

2. Application and properties

Extreme wear resistance, easy installation on single-part piston without assembly aids due to the split design of the sealing ring. Assembly on one-part piston is possible. Insensitive to extreme pressure peaks. Extreme high extreme pressure resistance. High pressure an large gaps due to the special compound properties of the seal ring. Dimensions according to ISO 7425-1. Short axial assembly length. Installation in closed and undercut housings. Additional sizes of machined products available on short notice.

3. Standard materials

Sealing ring: filled modified thermoplast

O-ring: NBR

4. Working Conditions

Working  Conditions
Diameter Range	Pressure Range	Temperature Range	Speed
25 - 480mm	0 - 80MPa	-30℃ +110℃	≤1 m/s

5. Installation Dimensions

D1	d1	L	Order No.
25 32 40	16 21 26.3	4.2 4.2 5.8	OK25*16*4.2 OK32*21*4.2 OK40*26.3*5.8
40 50 50	29 34.5 36.3	4.2 6.3 5.8	OK40*29*4.2 OK50*34.5*6.3 OK50*36.3*5.8
50 50 55	37 39 44	8 4.2 4.2	OK50*37*8 OK50*39*4.2 OK55*44*4.2
55 60 60	44 41.7 49	4.2 7 4.2	OK55*44*4.2 OK60*41.7*7 OK60*49*4.2
63 63 63	44.7 47.5 52	7 6.3 4.2	OK63*44.7*7 OK63*47.5*6.3 OK63*52*4.2
70 70 70	51.7 54.5 54.5	7 6.3 6.3	OK70*51.7*7 OK70*54.5*6.3 OK70*54.5*6.3
70 75 75	59 54 59.5	4.2 8 6.3	OK70*59*4.2 OK75*54*8 OK75*59.5*6.3
80 80 85	59 64.5 64	8 6.3 8	OK80*59*8 OK80*64.5*6.3 OK85*64*8
90 90 95	69 74.5 74	8 6.3 8	OK90*69*8 OK90*74.5*6.3 OK95*74*8
100 100 105	79 84.5 84	8 6.3 8	OK100*79*8 OK100*84.5*6.3 OK105*84*8
110 110 115	89 94.5 94	8 6.3 8	OK110*89*8 OK110*94.5*6.3 OK115*94*8
115 120 125	100 99 104	8 8 8	OK115*100*8 OK120*99*8 OK125*104*8
125 130 130	109.5 109 114.5	6.3 8 6.3	OK125*109.5*6.3 OK130*109*8 OK130*114.5*6.3
130 135 135	115 114 119.5	8 8 6.3	OK130*115*8 OK135*114*8 OK135*119.5*6.3
140 140 145	119 125 124	8 8 8	OK140*119*8 OK140*125*8 OK145*124*8
150 150 152.4	129 135 131.5	8 8 8	OK150*129*8 OK150*135*8 OK152.4*131.5*8
160 160 165	139 148 144	8 8 8	OK160*139*8 OK160*148*8 OK165*144*8
170 175 180	149 154 159	8 8 8	OK170*149*8 OK175*154*8 OK180*159*8
190 200 210	169 179 189	8 8 8	OK190*169*8 OK200*179*8 OK210*189*8
220 220 230	199 205 209	8 8 8	OK220*199*8 OK220*205*8 OK230*209*8
240 250 260	225 229 239	8 8 8	OK240*225*8 OK250*229*8 OK260*239*8
270 280 290	249 255.5 271	8 8 9.5	OK270*249*8 OK280*255.5*8 OK290*271*9.5
300 320 330	272 292 302	9.5 9.5 9.5	OK300*272*9.5 OK320*292*9.5 OK330*302*9.5
350 370 420	322 342 392	9.5 9.5 9.5	OK350*322*9.5 OK370*342*9.5 OK420*392*9.5
450 480	422 452	9.5 9.5	OK450*422*9.5 OK480*452*9.5

Company Features
1. DMS Seals focuses on providing reliable bucket cylinder seal kit and thoughtful service. Dms Seals Technology Co.,limited has a long history, with its kit seal cylinder product and technology in the leading position. Dms Seals Technology Co.,limited is a leading supplier of high quality hydraulic rod seal installer in global market.
2. We own a complete production house. It executes the strictest quality management control system in the industry. From R&D, design, raw materials selection, production, quality inspection, to product packaging, every stage in under scrutinization by professionals. We don't believe in the boundaries, especially in trade. Our products are exported via a worldwide distributor network to over 100 countries across all continents. The factory has newly introduced many state-of-the-art manufacturing facilities. These facilities are all developed under high techs and offer significant support for daily production demands. Our company has a strong and experienced technical development team. The team is able to offer diverse product solutions on customization, development, and product upgrade. Our factory complies with the highest international CSR standards. It has obtained the Worldwide Responsible Accredited Production (WRAP) certification.
3. Dms Seals Technology Co.,limited adheres to the business philosophy of honesty. Check now! We have refined a customer-centric belief system, focusing on delivering a positive experience and providing unparalleled levels of attention and support so customers can focus on growing their business. Our pledge to our customers is 'quality and safety'. We promise to manufacture safe, harmless, and non-toxic products for customers. We will devote greater efforts to quality inspection, including its ingredients of raw materials, components, and the whole structure.
