Wholesale hydraulic seal kits suppliers cost for light and medium hydraulic systems

Company Advantages
1. The design of DMS Seals meets the standards. It is conducted by our designers who assess the viability of the concepts, aesthetics, spatial layout, egonomics, and safety.
2. During the design of DMS Seals , a broad range of design elements have been taken in minds. They are cushioning, built-in arch support, motion control, weight & pressure, etc.
3. DMS Seals has passed the following pre-production processes. They are the development of fabric sample, pattern making, correction of pattern, pattern grading, approval of fabric, and testing of fabrics and other raw materials.
4. During the design stage of DMS Seals , many design factors have been taken into considerations. These factors mainly include space availability and functional layout.
5. Experts have testified to the excellent performance of hydraulic seal kits suppliers form Dms Seals Technology Co.,limited.
6. The high quality of the product has been approved by many international certifications.
7. With scientific structure and multiple functions, our hydraulic seal kits suppliers is unique.
8. The product has been greatly appreciated for its durability.
9. hydraulic seal kits suppliers enjoys high stable quality and well accepted by customers.
10. Under strict quality tests, hydraulic seal kits suppliers is of high quality when arriving to customers.
11. To reduce costs with high-efficiency work is the Dms Seals Technology Co.,limited's purpose.
12. Dms Seals Technology Co.,limited's hydraulic seal kits suppliers covers a wide sales network.
13. The quality of hydraulic seal kits suppliers can be guaranteed through .

1. Installation Recommendation

2. Application and properties

Suitable for long stroke, a wide range of fluids and high temperature occasions. The application of heavy duty double acting piston sealing under high pressure conditions is excellent. Applicable to larger piston clearance , it has good leakage control, extrusion resistance and wear resistance in heavy duty and construction machinery cylinder piston sealing system. Good static sealing property, simple groove structure, larger extrusion clearances can be allowed, be able to work in dusty condition.

3. Standard materials

Sealing ring: filled PTFE

O-Ring: NBR / FKM

Back-up ring: POM / PA

4. Working Conditions

Working  Conditions
Diameter Range	Pressure Range	Temperature Range	Speed	Medium
50 - 350mm	0 - 50MPa	-30℃ +100℃	1.5 m/s	hydraulic oil, flame retardant liquid, water and others

5. Installation Dimensions

Nominal Size of Packing, and Housing dimensions			L+0.2	Order No.
D1	dN	H
50 55 60	36 41 46	8.5 8.5 8.5	9 9 9	SPGW50*36*8.5 SPGW55*41*8.5 SPGW60*46*8.5
63 65 70	48 50 55	10.5 10.5 10.5	11 11 11	SPGW63*48*10.5 SPGW65*50*10.5 SPGW70*55*10.5
75 80 85	60 65 70	10.5 10.5 10.5	11 11 11	SPGW75*60*10.5 SPGW80*65*10.5 SPGW85*70*10.5
90 95 100	75 80 85	10.5 10.5 12	11 11 12.5	SPGW90*75*10.5 SPGW95*80*10.5 SPGW100*85*12
105 110 115	90 95 100	12 12 12	12.5 12.5 12.5	SPGW105*90*12 SPGW110*95*12 SPGW115*100*12
120 125 130	105 102 107	12 15.5 15.5	12.5 16 16	SPGW120*105*12 SPGW125*102*15.5 SPGW130*107*15.5
135 140 145	112 117 122	15.5 15.5 15.5	16 16 16	SPGW135*112*15.5 SPGW140*117*15.5 SPGW145*122*15.5
150 155 160	127 132 137	15.5 15.5 15.5	16 16 16	SPGW150*127*15.5 SPGW155*132*15.5 SPGW160*137*15.5
165 170 180	142 147 157	15.5 15.5 15.5	16 16 16	SPGW165*142*15.5 SPGW170*147*15.5 SPGW180*157*15.5
185 190 200	162 167 177	15.5 15.5 15.5	16 16 16	SPGW185*162*15.5 SPGW190*167*15.5 SPGW200*177*15.5
210 220 225	187 197 202	15.5 15.5 17	16 16 17.5	SPGW210*187*15.5 SPGW220*197*15.5 SPGW225*202*15.5
230 240 250	207 217 222	17 17 17	17.5 17.5 17.5	SPGW230*207*15.5 SPGW240*217*15.5 SPGW250*222*17
260 270 280	232 242 252	17 17 17	17.5 17.5 17.5	SPGW260*232*17 SPGW270*242*17 SPGW280*252*17
300 320 350	272 292 322	17 17 17	17.5 17.5 17.5	SPGW300*272*17 SPGW320*292*17 SPGW350*322*17

Company Features
1. Over the years of development, Dms Seals Technology Co.,limited has been flourishing in the industry. We have become an expert in the manufacturing of . Dms Seals Technology Co.,limited is a China-based company that has been specializing in the design and manufacture of . We have achieved a reputation for quality, service and competitive pricing. Since establishment, Dms Seals Technology Co.,limited has been providing high performance services for the market. As a manufacture company, Dms Seals Technology Co.,limited serves market-leading companies for many years and has been regarded as a reliable supplier. Dms Seals Technology Co.,limited, a company specializing in the manufacture of in China, has ample experience in product design and development.
2. We have adapted to the demands of a growing and rapidly changing industry. We now boast a large sophisticated facility, the highest quality standards in the industry and a dynamic research and development team. Our company has a team of experts. They have expertise in their area of ​​expertise and assist the company in the production of products in accordance with customer instructions. Our factory seriously sticks to the quality management system. Under the scrutinization of this system, all of the products will be checked by professional staff and tested by advanced equipment to make sure there is no nonconform product. Our factory is equipped with compatible and adaptable modern production facilities. They are perfectly suited to offer scalable manufacture, from one-off custom design products, right up to bulk production runs.
3. The quality of the service has been highly stressed by DMS Seals. Contact! DMS Seals brand now abides by improving the quality of the service. Contact! The unforgettable development history tells DMS Seals people that only by continuous innovation can companies achieve significant development. Contact! Dms Seals Technology Co.,limited will further enhance its sense of social responsibility. Contact! With excellent service, DMS Seals has been spoken highly of by customers at home and abroad. Contact!
