custom glyd ring glyd ring for piston and hydraulic cylinder

Company Advantages
1. DMS Seal Manufacturer glyd ring is manufactured by our team of skilled experts as per the international quality standards.
2. DMS Seal Manufacturer glyd ring is manufactured using fine quality raw material under the supervision of experienced professionals.
3. These DMS Seal Manufacturer piston o ring are designed and developed in line with industry norms and standards.
4. Mature and stable production process ensures glyd ring has perfect product performance.
5. The product has been approved by many international certifications.
6. The product has succeeded in attaining exceptional value of stable performance and strong practicality.
7. The product quality is doubly guaranteed by professional QC team and sophisticated testing equipment.
8. glyd ring has the advantages of piston o ring , and reduced overall cost.
9. The successful establishment of sales network better guaranteed the development of DMS Seal Manufacturer.
10. DMS Seal Manufacturer is a professional company who designs and features producing exquisite glyd ring with advanced technology.
11. By serving clients well, DMS Seal Manufacturer has won a lot of praises.

1. Installation Recommendation

2. Installation Sizes

Bore Diameter                         DN H9			Groove Diameter	Groove Width	Radius	Radial Clearance                S max.			O-Ring Cross-Section
Standard Application	Light Application	Heavy Duty Application	d1 h9	L1+0.2	R1	10MPa	20MPa	40MPa	d2
8-14.9	15-39.9	-	DN-4.9	2.2	0.4	0.3	0.20	0.15	1.78
15-39.9	40-79.9	-	DN-7.5	3.2	0.6	0.4	0.25	0.15	2.62
40-79.9	80-132.9	15-39.9	DN-11.0	4.2	1.0	0.4	0.25	0.20	3.53
80-132.9	133-329.9	40-79.9	DN-15.5	6.3	1.3	0.5	0.30	0.20	5.33
133-329.9	330-699.9	80-132.9	DN-21.0	8.1	1.8	0.6	0.35	0.25	7.00
330-669.9	670-99.9	133-329.9	DN-24.5	8.1	1.8	0.6	0.35	0.25	7.00
670-999.9	≥1000	330-669.9	DN-28.0	9.5	2.5	0.7	0.50	0.30	8.40
≥1000	≥1000	≥1000	DN-38.0	13.8	3.0	1.0	0.70	0.60	12.00

3. Application and properties

Standard double acting seal. Suitable for reciprocating motion, allowing larger extrusion clearances, has wide application. Dynamic and static sealing property are excellent, be able to work in dusty condition. Low friction, simple groove, strong adaptability to work conditions.



4. Standard materials

Sealing ring: filled PTFE

O-Ring: NBR / FKM



5. Working Conditions

Working  Conditions
Diameter Range	Pressure Range	Temperature Range	Speed	Medium
3 - 1600mm	0 - 60MPa	-45℃ +200℃	15 m/s	hydraulic oil, flame retardant liquid, water and others



6. Installation Dimensions

Bore Dia.	Groove Dia.	Groove Width	Order No.	O-Ring Dimensions
DN H9	d1 h9	L1+0.2
8 10 12	3.1 5.1 7.1	2.2 2.2 2.2	GSF8*3.1*2.2 GSF10*5.1*2.2 GSF12*7.1*2.2	2.90*1.78 4.80*1.8 6.70*1.8
14 15 15	9.1 10.1 7.5	2.2 2.2 3.2	GSF14*9.1*2.2 GSF15*10.1*2.2 GSF15*7.5*3.2	8.75*1.8 7.59*2.62 8.75*1.8
16 16 18	11.1 8.5 13.1	2.2 3.2 2.2	GSF16*11.1*2.2 GSF16*8.5*3.2 GSF18*13.1*2.2	10.82*1.78 7.59*2.62 12.42*1.78
18 20 20	10.5 15.1 12.5	3.2 2.2 3.2	GSF18*10.5*3.2 GSF20*15.1*2.2 GSF20*12.5*3.2	9.19*2.62 14.00*1.78 12.37*2.62
24 24 25	19.1 16.5 17.5	2.2 3.2 3.2	GSF24*19.1*2.2 GSF24*16.5*3.2 GSF25*17.5*3.2	18.77*1.78 15.54*2.62 17.12*2.62
25 28 28	14 20.5 17	4.2 3.2 4.2	GSF25*14*4.2 GSF28*20.5*3.2 GSF28*17*4.2	13.87*3.53 20.29*2.62 15.47*3.53
30 30 32	22.5 19 24.5	3.2 4.2 3.2	GSF30*22.5*3.2 GSF30*19*4.2 GSF32*24.5*3.2	21.89*2.62 26.70*1.78 23.47*2.62

Company Features
1. Dms Seals Technology Co.,limited has been specialized in manufacturing glyd ring with affordable price. Dms Seals Technology Co.,limited is a high-strength and export-oriented enterprise specializing in the production and export of piston seals . The past years has witnessed steadily gowning development of Dms Seals Technology Co.,limited for its rod seal . Dms Seals Technology Co.,limited primarily provides high quality hydraulic cylinder piston seals . Leading the hydraulic rod seals industry is the position that DMS Seal Manufacturer stands.
2. To satisfy the needs of technical innovation in this society, our experienced team has been researching and developing glyd ring persistently. Dms Seals Technology Co.,limited owns advanced production equipment and sophisticated testing equipment. Dms Seals Technology Co.,limited has set up with a strict quality control system. Thanks to piston o ring technology, our glyd ring is especially popular in this field. Produced by advanced machine and mature technology, glyd ring is of great performance.
3. It is a fact that DMS Seal Manufacturer has been keeping the idea of glyd ring first in mind since founded. Contact! What we aim to do is that we devote ourselves into developing glyd ring with highest quality and favored price wholeheartedly. Contact! Dms Seals Technology Co.,limited uses ptfe o ring for the purpose of tenet. Contact! hydraulic seals catalogue brand strategy constitute the core competitiveness of Dms Seals Technology Co.,limited. Contact! Thanks to the enterprise culture of DMS Seal Manufacturer, we all aim to strive forward at one direction. Contact!
