ddkk piston seals glyd ring for sale DMS Seal Manufacturer

Company Advantages
1. Dms Seals Technology Co.,limited provides different designs of piston seals for your choice.
2. Dms Seals Technology Co.,limited has always put great importance to quality stability of piston seals .
3. rubber piston seals materials are used in Dms Seals Technology Co.,limited's piston seals manufacturing.
4. Comparing with the rubber piston seals, our piston seals have some characteristic as following:
5. All the piston seals are reliable in property and reputably appraised by customers.
6. The product is exmained by a accomplished team to ensure the reliability of functions.
7. The reliable quality and high extra value make piston seals have the industrial value of popularization and application.
8. piston seals functions perfectly in the development of the multiple application needs.
9. The product quality is assured after hundreds of testings.
10. Dms Seals Technology Co.,limited has world-wide sales network and manufacturing base.
11. Our solid package will ensure no damage for piston seals .
12. DMS Seal Manufacturer is a leading manufacturer of piston seals which covers a wide range of rubber piston seals.
13. Dms Seals Technology Co.,limited strictly complies with ISO standard manufacturing processes for our piston seals .
14. Dms Seals Technology Co.,limited will greatly value every suggestion from customers and make accordingly measures to improve.

1. Installation Recommendation

2. Application and properties

Suitable for long stroke, a wide range of fluids and high temperature occasions. The application of heavy duty double acting piston sealing under high pressure conditions is excellent. Applicable to larger piston clearance , it has good leakage control, extrusion resistance and wear resistance in heavy duty and construction machinery cylinder piston sealing system. Good static sealing property, simple groove structure, larger extrusion clearances can be allowed, be able to work in dusty condition.

3. Standard materials

Sealing ring: filled PTFE

O-Ring: NBR / FKM

Back-up ring: POM / PA

4. Working Conditions

Working  Conditions
Diameter Range	Pressure Range	Temperature Range	Speed	Medium
50 - 350mm	0 - 50MPa	-30℃ +100℃	1.5 m/s	hydraulic oil, flame retardant liquid, water and others

5. Installation Dimensions

Nominal Size of Packing, and Housing dimensions			L+0.2	Order No.
D1	dN	H
50 55 60	36 41 46	8.5 8.5 8.5	9 9 9	SPGW50*36*8.5 SPGW55*41*8.5 SPGW60*46*8.5
63 65 70	48 50 55	10.5 10.5 10.5	11 11 11	SPGW63*48*10.5 SPGW65*50*10.5 SPGW70*55*10.5
75 80 85	60 65 70	10.5 10.5 10.5	11 11 11	SPGW75*60*10.5 SPGW80*65*10.5 SPGW85*70*10.5
90 95 100	75 80 85	10.5 10.5 12	11 11 12.5	SPGW90*75*10.5 SPGW95*80*10.5 SPGW100*85*12
105 110 115	90 95 100	12 12 12	12.5 12.5 12.5	SPGW105*90*12 SPGW110*95*12 SPGW115*100*12
120 125 130	105 102 107	12 15.5 15.5	12.5 16 16	SPGW120*105*12 SPGW125*102*15.5 SPGW130*107*15.5
135 140 145	112 117 122	15.5 15.5 15.5	16 16 16	SPGW135*112*15.5 SPGW140*117*15.5 SPGW145*122*15.5
150 155 160	127 132 137	15.5 15.5 15.5	16 16 16	SPGW150*127*15.5 SPGW155*132*15.5 SPGW160*137*15.5
165 170 180	142 147 157	15.5 15.5 15.5	16 16 16	SPGW165*142*15.5 SPGW170*147*15.5 SPGW180*157*15.5
185 190 200	162 167 177	15.5 15.5 15.5	16 16 16	SPGW185*162*15.5 SPGW190*167*15.5 SPGW200*177*15.5
210 220 225	187 197 202	15.5 15.5 17	16 16 17.5	SPGW210*187*15.5 SPGW220*197*15.5 SPGW225*202*15.5
230 240 250	207 217 222	17 17 17	17.5 17.5 17.5	SPGW230*207*15.5 SPGW240*217*15.5 SPGW250*222*17
260 270 280	232 242 252	17 17 17	17.5 17.5 17.5	SPGW260*232*17 SPGW270*242*17 SPGW280*252*17
300 320 350	272 292 322	17 17 17	17.5 17.5 17.5	SPGW300*272*17 SPGW320*292*17 SPGW350*322*17

Company Features
1. Dms Seals Technology Co.,limited is a piston seals manufacturers who make the best high-end range. With years of research and development, DMS Seal Manufacturer is strong enough to provide hydraulic piston seals . Dms Seals Technology Co.,limited is an initiator in the industry of o-ring seal. Dms Seals Technology Co.,limited gathers leading products, systems and solutions, is a professional piston seals supplier. Dms Seals Technology Co.,limited, focusing on the production and R&D of piston seals , is famous at home and abroad.
2. DMS Seal Manufacturer has its own labs for the R&D, design, and production of piston seals . Dms Seals Technology Co.,limited has powerful economic strength and technical advantage. By keeping innovating the piston seals technology, we can stay ahead in the industry. DMS Seal Manufacturer keeps introducing technologies to produce piston seals . DMS Seal Manufacturer accomplishes great achievement the high quality of the piston seals .
3. The way that we fulfill social responsibility is to practice sustainable development. We have made a plan to reduce carbon footprint and we will execute all the time. Get an offer! We can provide an abundance of piston seals with high quality. Get an offer! We manage our business by our core values of balance, commitment, customer focus, integrity, and quality. Each member of our team lives by and practices these values every day. Our mission is to provide our clients and employees the means to reach their maximum potential. We do that by creating world-class manufacturing environments, building innovative teams, and by making a positive impact on the communities where we operate. Dms Seals Technology Co.,limited is committed to serving the best interests of our customers.

ddkk piston seals glyd ring for sale DMS Seal Manufacturer

piston seals

Type:ddkk 、 Type1:gsfw
