dkdf piston seals with ptfe nbr and pom for pneumatic equipment DMS Seal Manufacturer
1. hydraulic piston seals suppliers makes piston seals very competitive in the market.
2. High quality material and independent design immensely raise the reputation for DMS Seal Manufacturer.
3. DMS Seal Manufacturer hydraulic piston seals suppliers is produced in a standardized production environment.
4. The product design principle and the structure of piston seals have obtained national patents.
5. The quality testing procedure of this product is extremely rigorous.
6. The strict quality control process is carried out throughout the whole production eliminates the possible defects of the product.
7. The quality of the product has been greatly enhanced as the production technology has been improved.
8. This projector screen is perfect for outdoor birthday parties, wedding parties, poolside parties or simply a movie night party.
9. The easiest way to make a dirty pool look clean is to clean it using this product. One of our customers said.
10. People can find this product is widely applied in many items, ranging from bedding to bath, kitchen and table fabric items, and most obviously, apparel.
11. This product is popular. It would typically be seen in rooms that are built as a space in which presentations of some kind would take place.
Bore Diameter DN H9 | Groove Diameter | Groove Width | Radius | Radial Clearance S max. | O-Ring Cross-Section | ||||
Standard Application | Light Application | Heavy Duty Application | d1 h9 | L1+0.2 | R1 | 10MPa | 20MPa | 40MPa | d2 |
8-16.9 | 17-26.9 | -- | DN-4.9 | 2.2 | 0.4 | 0.30 | 0.20 | 0.15 | 1.78 |
17-26.9 | 27-59.9 | -- | DN-7.3 | 3.2 | 0.6 | 0.40 | 0.25 | 0.15 | 2.62 |
27-59.9 | 60-199.9 | 17-26.9 | DN-10.7 | 4.2 | 1.0 | 0.50 | 0.30 | 0.20 | 3.53 |
60-199.9 | 200-255.9 | 27-59.9 | DN-15.1 | 6.3 | 1.3 | 0.70 | 0.40 | 0.25 | 5.33 |
200-255.9 | 256-669.9 | 60-199.9 | DN-20.5 | 8.1 | 1.8 | 0.80 | 0.60 | 0.35 | 7.00 |
256-669.9 | 670-999.9 | 200-669.9 | DN-24.0 | 8.1 | 1.8 | 0.90 | 0.70 | 0.40 | 7.00 |
670-999.9 | -- | 256-669.9 | DN-28.0 | 9.5 | 2.5 | 1.00 | 0.80 | 0.60 | 8.40 |
-- | 1000-2000 | -- | DN-28.0 | 9.5 | 2.5 | 1.00 | 0.80 | 0.60 | 8.40 |
-- | -- | 670-999.9 | DN-38.0 | 13.8 | 3.0 | 1.20 | 0.90 | 0.60 | 12.00 |
1000-2700 | -- | -- | DN-38.0 | 13.8 | 3.0 | 1.20 | 0.90 | 0.60 | 12.00 |
Application and properties
Standard single acting sealing. Suitable for reciprocating environment, allowing larger extrusion clearances, has wide application. Dynamic and static sealing property are good, be able to work in dusty condition. Low friction, simple groove, strong adaptability to work conditions.
Standard materials
Sealing ring: filled PTFE
O-ring: NBR / FKM
Working Conditions | ||||
Diameter Range | Pressure Range | Temperature Range | Speed | Medium |
3-1600mm | 0-60MPa | -45℃ +200℃ | 15 m/s | hydraulic oil, flame retardant liquid, water and others |
Bore Dia. | Groove Dia. | Width | Order No. | O-ring Dimension |
D H9 | d1 h9 | L1+0.2 | ||
9 | 4.1 | 2.2 | GSD9*4.1*2.2 | 3.68*1.78 |
15 | 10.1 | 2.2 | GSD15*10.1*2.2 | 9.25*1.78 |
20 | 12.7 | 3.2 | GSD20*12.7*3.2 | 12.37*2.62 |
27 | 16.3 | 4.2 | GSD27*16.3*4.2 | 15.47*3.53 |
32 | 24.7 | 3.2 | GSD32*24.7*3.2 | 23.47*2.62 |
36 | 25.3 | 4.2 | GSD36*25.3*4.2 | 24*3.53 |
40 | 29.9 | 4.2 | GSD40*29.3*4.2 | 28.17*3.53 |
50 | 39.3 | 4.2 | GSD50*39.3*4.2 | 37.70*3.53 |
55 | 44.3 | 4.2 | GSD55*44.3*4.2 | 44.04*3.53 |
63 | 47.9 | 6.3 | GSD63*47.9*6.3 | 46.99*5.33 |
70 | 59.3 | 4.2 | GSD70*59.3*4.2 | 56.74*3.53 |
80 | 64.9 | 6.3 | GSD80*64.9*6.3 | 62.87*5.33 |
90 | 74.9 | 6.3 | GSD90*74.9*6.3 | 72.39*5.33 |
95 | 74.5 | 8.1 | GSD95*74.5*8.1 | 73*7.0 |
110 | 94.9 | 6.3 | GSD110*94.9*6.3 | 91.44*5.33 |
Company Features
1. DMS Seal Manufacturer is a company that specializes in manufacturing piston seals . The past years has witnessed steadily gowning development of Dms Seals Technology Co.,limited for its o-ring seal. With great input, Dms Seals Technology Co.,limited has rapidly become a world-class leader in hydraulic piston seals industries. With core advantage of hydraulic piston seals suppliers , Dms Seals Technology Co.,limited takes the lead in field of piston seals .
2. Dms Seals Technology Co.,limited has advanced production equipments and rich technical strength. DMS Seal Manufacturer is very strong in R&D. The strong R&D team is the continuous developing power resource of DMS Seal Manufacturer. Each part of piston seals will be checked by our professional QC department.
3. A central tenet of Dms Seals Technology Co.,limited could be summarized as pneumatic piston seals . Ask! Dms Seals Technology Co.,limited won good reputation for its tenet of hydraulic piston seals . Ask! Our factory always keep rubber piston seals as the tenet. Ask! Dms Seals Technology Co.,limited provide reliable scheme with hydraulic piston seals sizes . Ask!
dkdf piston seals with ptfe nbr and pom for pneumatic equipment DMS Seal Manufacturer
piston seals
Type:dkdf、 Type1:spg
