DMS Seal Manufacturer Brand oring hydraulic seal custom hydraulic rod seals

Diameter Range:

3-1600mm

Pressure Range:

0-35MPa

Temperature Range:

-30℃+200℃

Speed:

1.5m/s

Medium:

general hydraulic oil, water glycol hydraulic oil, oil / water emulsion type hydraulic oil.

Inquiry

Company Advantages
1. Unmatched expertise of DMS Seal Manufacturer enables us to serve our clients with utmost accuracy than our industry competitors. DMS Seals implements and optimizes its quality control systems
2. The adoption of hydraulic rod seals method can cause piston rod seal and satisfy production requirements. As a modern sealing technology company, DMS Seal manufacturer has a wealth of experience
3. Following the trend of fashion, our rod seals is designed to be of hydraulic rod seals online and rod seal catalogue. DMS Seal manufacturer is a technology enterprise which specialized in the R&D and production of seals
4. With this in mind, it has been our mission to continually evolve our know-how, giving you access to qualified technology expertise that can be applied to create the next generation of hydraulic rod seals products. DMS o-ring seal has advanced machines and equipment for its production
5. We can support OEM and ODM. O Ring Manufacturers,pneumatic rod seals is applicable to industries of push rod seal.

Installation Recommendation

undefined

Application and properties

Applicable to a wide range of pressure work and sliding high speed occasions. Standard combined seal. Low friction, strong wear resistance.

Standard materials

Sealing ring: filled PTFE

O-Ring: NBR / FKM

Working Conditions

Working Conditions
Diameter Range	Pressure Range	Temperature Range	Speed	Medium
3-1600mm	0-35MPa	-30℃+200℃	1.5 m/s	general hydraulic oil, water glycol hydraulic oil, oil / water emulsion type hydraulic oil.

Installation Dimensions

Nominal Size of Packing, and Housing dimensions				Order No.
d	D	H	L +0.2	Order No.
12 14 16	18 20 22	3.0 3.0 3.0	3.2 3.2 3.2	SPNO12183.2 SPNO14203.2 SPNO16223.2
18 20 22	24 26 31	3.0 3.0 3.8	3.2 3.2 4	SPNO18243.2 SPNO20263.2 SPNO22314
25 28 30	34 37 39	3.8 3.8 3.8	4 4 4	SPNO25344 SPNO28374 SPNO30394
32 36 40	41 45 49	3.8 3.8 3.8	4 4 4	SPNO32414 SPNO36454 SPNO40494
45 50 56	54 65 71	3.8 6.3 6.3	4 6.5 6.5	SPNO45544 SPNO50656.5 SPNO56716.5
60 63 70	75 78 85	6.3 6.3 6.3	6.5 6.5 6.5	SPNO60756.5 SPNO63786.5 SPNO70856.5
75 80 85	90 95 100	6.3 6.3 6.3	6.5 6.5 6.5	SPNO75906.5 SPNO80956.5 SPNO851006.5
90 95 100	105 110 115	6.3 6.3 6.3	6.5 6.5 6.5	SPNO901056.5 SPNO951106.5 SPNO1001156.5
105 110 115	120 125 130	6.3 6.3 6.3	6.5 6.5 6.5	SPNO1051206.5 SPNO1101256.5 SPNO1151306.5
120 125 130	135 140 145	6.3 6.3 6.3	6.5 6.5 6.5	SPNO1201356.5 SPNO1251406.5 SPNO1301456.5
135 140 145	150 155 160	6.3 6.3 6.3	6.5 6.5 6.5	SPNO1351506.5 SPNO1401556.5 SPNO1451606.5
150 160 170	170 180 190	9.8 9.8 9.8	10 10 10	SPNO15017010 SPNO16018010 SPNO17019010

Installation Dimensions

Company Features
1. Dms Seals Technology Co.,limited owns manufacturing facilities.
2. Dms Seals Technology Co.,limited make every effort to have hydraulic rod seals in this rod seals. Inquire!

we welcome custom designs and ideas and is able to cater to the specific requirements. for more information, please visit the website or contact us directly with questions or inquiries.
