DMS Seals - Hydraulic Seals and Oil Ring Seals Manufacturer & Supplier
DMS Seal Manufacturer ptfe hydraulic piston seals suppliers for light and medium hydraulic systems
- Dms Seals insists on the principle to focus on customer and service. According to the customer's different needs, we provide relevant solutions and good user experiences.
1. piston seals use hydraulic piston seals suppliers design for better performance and long service life.
2. hydraulic piston seals suppliers materials are used in Dms Seals Technology Co.,limited's piston seals manufacturing.
3. The material selection of piston seals always take hydraulic piston seals suppliers into account.
4. Our product is widely demanded due to selected quality of hydraulic piston seals suppliers which is durable and excellent.
5. Dms Seals Technology Co.,limited puts a high value on material of piston seals , which wins customers' trust.
6. Compared with the traditional hydraulic piston seals suppliers , the newly designed piston seals is superior for its pneumatic piston seals .
7. piston seals firstly take satisfying consumers' demand as aim.
8. With the hydraulic piston seals suppliers ,it's unnecessary for you to worry about quality problem.
9. The great operation of hydraulic piston seals suppliers indicates the high performance of piston seals .
10. piston seals is flexible which can be adjusted by different circumstances.
11. The translucent feature of this product makes it perfect for the cooks who enjoy using it for culinary creations and decoration.
12. The product is an excellent solution for camping activity. Customers who bought this product are happy to use this product when they have family gathering activities.
13. People will find it easy to rinse or dishwasher safe, which saves the host much effort in cleaning during dining or gathering parties.
14. This was exactly what I needed. This product has a good refrigeration effect, which allows me to take care of my goods needed to be refrigerated. - One customer said this.
15. There are lots of benefits of investing in this product such as improvements in working efficiency to sustain patients' health.
Groove Diameter DN H9 | Groove Diameter | Groove Width | Radius | Radial Clearance S max. | O-Ring Cross Section | X-Ring Seal Cross Section | |||
Standard Application | Light Application | d1 h9 | L1+0.2 | R1 | 10MPa | 20MPa | 30MPa | d2 | W |
15 - 39.9 | 40 - 79.9 | DN - 11.0 | 4.2 | 1.0 | 0.25 | 0.15 | 0.10 | 3.53 | 1.78 |
40 - 79.9 | 80 - 132.9 | DN - 15.5 | 6.3 | 1.3 | 0.3 | 020 | 0.15 | 5.33 | 1.78 |
80 - 132.9 | 133 - 252.9 | DN - 21.0 | 8.1 | 1.8 | 0.3 | 0.20 | 0.15 | 7.00 | 2.62 |
133 - 252.9 | -- | DN - 24.5 | 8.1 | 1.8 | 0.3 | 0.20 | 0.15 | 7.00 | 2.62 |
253 - 462.9 | -- | DN - 28.0 | 9.5 | 2.5 | 0.45 | 0.30 | 0.25 | 8.40 | 3.53 |
463 - 700 | -- | DN - 35.0 | 11.5 | 3.0 | 0.55 | 0.40 | 0.35 | 10.00 | 5.33 |
Application and properties
Apply to the working condition of fast speed, high pressure, and the necessary pressure keeping. Recommended for double-acting pistons as piston-type energy storage, supporting cylinder and positional cylinder. Double safety with low friction and high elasticity, good dynamic and static sealing performance, larger extrusion clearances can be allowed, at the same time with the function of holding pressure, less leakage in the hydraulic cylinder. Simple groove, small installation space, excellent sliding performance, no crawling phenomenon.
Standard materials
Sealing ring: filled PTFE
O-Ring: NBR / FKM
X-Ring: NBR / FKM
Working Conditions | ||||
Diameter Range | Pressure Range | Temperature Range | Speed | Medium |
3-1600mm | 0-40MPa | -30℃+200℃ | 2 m/s | hydraulic oil, flame retardant liquid, water and others |
Bore Dia. | Groove Dia. | Groove Width | Order No. | O-Ring Dimension |
d h9 | D1 H9 | L1+0.2 | ||
70 | 59 | 4.2 | DAQ70*59*4.2 | 56.74*3.53 |
80 | 64.5 | 6.3 | DAQ80*64.5*6.3 | 62.87*5.33 |
85 | 64 | 8.1 | DAQ85*64*8.1 | 63*7.0 |
95 | 79.5 | 6.3 | DAQ95*79.5*6.3 | 78.74*5.33 |
100 | 79 | 8.1 | DAQ100*79*8.1 | 78*7.0 |
110 | 94.5 | 6.3 | DAQ110*94.5*6.3 | 91.44*5.33 |
115 | 94 | 8.1 | DAQ115*94*8.1 | 93*7.0 |
125 | 109.5 | 6.3 | DAQ125*109.5*6.3 | 107.32*5.33 |
130 | 109 | 8.1 | DAQ130*109*8.1 | 108*7.0 |
150 | 129 | 8.1 | DAQ150*129*8.1 | 126.37*7.0 |
180 | 159 | 8.1 | DAQ180*159*8.1 | 158.12*7.0 |
210 | 189 | 8.1 | DAQ210*189*8.1 | 183.52*7.0 |
240 | 219 | 8.1 | DAQ240*219*8.1 | 215.27*7.0 |
Company Features
1. Dms Seals Technology Co.,limited has a high level of professionalism in production of piston seals . Dms Seals Technology Co.,limited is a leader in the progress and innovation of the entire o-ring seal industry. DMS Seal Manufacturer has rich experience in producing hydraulic piston seals . Dms Seals Technology Co.,limited produces exquisite piston seals superior to other companies.
2. Dms Seals Technology Co.,limited is the larger of hydraulic piston seals suppliers production base. Dms Seals Technology Co.,limited has successfully got several patents for technology. Dms Seals Technology Co.,limited's piston seals are integrated domestic and foreign advanced technologies.
3. DMS Seal Manufacturer believes that by the aspiration of piston seals , we can maintain effective growth in the long term. Please contact us! Creating value for both DMS Seal Manufacturer and customers is a motivation for the development of company. Please contact us! In the future, DMS Seal Manufacturer will strive to contribute to the community with first-class technology, first-class management, first-class products and first-class service. Please contact us! Our mission is to develop innovative piston seals that create pneumatic piston seals . Please contact us!
DMS Seal Manufacturer ptfe hydraulic piston seals suppliers for light and medium hydraulic systems
