DMS Seal Manufacturer push rod seal Suppliers for pressure work and sliding high speed occasions

Company Advantages
1. Every detail of DMS Seal Manufacturer is professionally handled by designers who have years of experience in architecture design. The product's surface, edges, and colors are exquisitely determined to match the room.
2. The quality inspections of DMS Seal Manufacturer cover different aspects. These inspections include thickness tolerance, flatness, thermal stability, anti-bending capability, and colorfastness.
3. The creation of DMS Seal Manufacturer strictly meets the requirements of European safety standards including EN standards and norms, REACH, TüV, FSC, and Oeko-Tex.
4. DMS Seal Manufacturer has been inspected to meet general quality standards. It has been tested in respect of colorfastness, stitching strength, seam strength, size-change, and seam-twisting.
5. The key things to consider in designing DMS Seal Manufacturer are: Aspect Ratio, Viewing angle, Gain, Fixed or retractable, Masking system, Acoustically transparent or not, Boarder type and Environment light level.
6. The product is eco-friendly. The wood used in it is of top quality from reliable sources that do not cause deforestation or endanger rare trees.
7. It is characterized by its remarkable temperature resistance. High-temperature oxidation resistant coating, which may react with the active molecule under high temperature, is applied on the surface.
8. The product provides the desired stability. Its heel support/heel cup is soft and stable, preventing vertical or horizontal heel movement.
9. The product is resilient to vibration and impact. It has been manufactured by casting, milling, or forging to be more resilient.
10. This product is widely used in the market due to its huge economic potential.
11. The product is able to maximum satisfaction to the clients and is now widely used in the market.
12. This product has many excellent properties and can be widely used.

1. Installation Recommendation

2. Installation Sizes

Rod Diameter d e8	Groove Diameter D H9	Groove Width L D10	H
20-56	d+10	16	15
57-140	d+13	16	15
＞140	d+15	16	15

3. Application and properties

Suitable for tandem type internal sealing, and can be used as fluid sealing and dust sealing simultaneously. Excellent sealing effect can be achieved in case of no pressure. Easy installation, wear-resisting, anti extrusion, low friction, non stick slip phenomenon.

4. Standard materials

Sealing ring: filled PTFE

O-Ring: NBR / PU

5. Working Conditions

Working  Conditions
Diameter Range	Pressure Range	Temperature Range	Speed	Medium
3 - 1600mm	0 - 25MPa	-30℃ + 100℃	1 m/s	hydraulic oil, flame retardant liquid, water, gas

6. Installation Dimensions

d e8	D1 H9	H	L D10	e	Order No.
50 55 56	60 65 66	15 15 15	16 16 16	6 6 6	MDI50*60*15 MDI55*65*15 MDI56*66*15
60 63 65	73 76 78	15 15 15	16 16 16	7 7 7	MDI60*73*15 MDI63*76*15 MDI65*78*15
70 72 75	83 85 88	15 15 15	16 16 16	7 7 7	MDI70*83*15 MDI72*85*15 MDI75*88*15
80 85 90	93 98 103	15 15 15	16 16 16	7 7 7	MDI80*93*15 MDI85*98*15 MDI90*103*15
95 100 105	108 113 118	15 15 15	16 16 16	7 7 10	MDI95*108*15 MDI100*113*15 MDI105*118*15
110 110 115	120 123 128	15 15 15	16 16 16	10 10 10	MDI110*120*15 MDI110*123*15 MDI115*128*15
120 125 130	133 138 143	15 15 15	16 16 16	10 10 10	MDI120*133*15 MDI125*138*15 MDI130*143*15
140 150 150	153 162 165	15 15 15	16 16 16	10 10 10	MDI140*153*15 MDI150*162*15 MDI150*165*15
160 165 170	175 180 185	15 15 15	16 16 16	10 10 10	MDI160*175*15 MDI165*180*15 MDI170*185*15
180 185 190	195 200 205	15 15 15	16 16 16	10 10 10	MDI180*195*15 MDI185*200*15 MDI190*205*15

Company Features
1. Integrating with advanced machine and world-class technology, DMS Seal Manufacturer always develops unique push rod seal . At the forefront in the field of rod end seals , Dms Seals Technology Co.,limited has received much more recognition. Dms Seals Technology Co.,limited focuses on research and development of high-quality rod seal design products. Dms Seals Technology Co.,limited has been the OEM supplier for a many famous hydraulic seal kits suppliers brand since its inception.
2. By using our advanced machines, there are few defected rod seal catalogue provided. The company possesses excellent technical and R&D team who develop innovative products with rigorous attitude and strict standards and proactively push the industry moving forward. We have an in-house team of award-winning designers. They allow the company to support customers throughout all stages of product development to ensure the process is fluid and holistic. The company has high-quality engineering personnel, professional sales staff and skilled technical workers. Dms Seals Technology Co.,limited is superior to other companies in piston rod seal technology.
3. DMS Seal Manufacturer will boost its global fluency in the hydraulic wiper market. Get quote! Dms Seals Technology Co.,limited positions itself as a long-term partner from the hydraulic ram seals online field. Get quote! Dms Seals Technology Co.,limited intends to boost the brand's reputation and encourage customer growth. Get quote! DMS Seal Manufacturer adheres to the idea of the customer first. Get quote! DMS Seal Manufacturer will carry forward the spirit of enterprise and provide customers with the most valuable service. Get quote!
