DMS Seal Manufacturer Top hydraulic piston seals suppliers for business for sale

Company Advantages
1. The testing for DMS Seal Manufacturer consists of a series of safety and EMC tests which are performed to certify that a product will not suffer from interference in the applicable medical environment.
2. DMS Seal Manufacturer manufactured by our professional engineers are made to run on natural refrigerant agents rather than traditional synthetics agents used as refrigerants which is the key factor in harmful pollutant reduction.
3. DMS Seal Manufacturer has been tested by the third-party testing organization in terms of mechanical testing, product qualification, material characterization, and microbiological evaluation.
4. Because of the high levels of heat produced by DMS Seal Manufacturer , the aluminum PCB board that contains a thin layer of dielectric that allows quicker heat dissipation is attached to printed boards.
5. hydraulic piston seals suppliers is well sold throughout the country and is well received by users.
6. The product has been subjected to comprehensive functional and endurance tests before leaving the factory.
7. A professional quality inspection team is allocated to ensure the product is always of the superior quality.
8. It attracts users' attention with its easy-to-use performance.
9. Many scientific and strict inspection means have been applied to ensure the premium quality of the product.
10. The product, highly recommended by users, has great market potential.
11. Available in different specifications, the product is highly demanded among customers owing to its high economic return.
12. This product is suitable for each domain, has the broad market prospect.
13. This product has great economic benefits and huge market potential.
14. The product has many usages and is widely used by people from various fields.

1. Installation Recommendation

2. Application and properties

Suitable for long stroke, a wide range of fluids and high temperature occasions. The application of heavy duty double acting piston sealing under high pressure conditions is excellent. Applicable to larger piston clearance , it has good leakage control, extrusion resistance and wear resistance in heavy duty and construction machinery cylinder piston sealing system. Good static sealing property, simple groove structure, larger extrusion clearances can be allowed, be able to work in dusty condition.

3. Standard materials

Sealing ring: filled PTFE

O-Ring: NBR / FKM

Back-up ring: POM / PA

4. Working Conditions

Working  Conditions
Diameter Range	Pressure Range	Temperature Range	Speed	Medium
50 - 350mm	0 - 50MPa	-30℃ +100℃	1.5 m/s	hydraulic oil, flame retardant liquid, water and others

5. Installation Dimensions

Nominal Size of Packing, and Housing dimensions			L+0.2	Order No.
D1	dN	H
50 55 60	36 41 46	8.5 8.5 8.5	9 9 9	SPGW50*36*8.5 SPGW55*41*8.5 SPGW60*46*8.5
63 65 70	48 50 55	10.5 10.5 10.5	11 11 11	SPGW63*48*10.5 SPGW65*50*10.5 SPGW70*55*10.5
75 80 85	60 65 70	10.5 10.5 10.5	11 11 11	SPGW75*60*10.5 SPGW80*65*10.5 SPGW85*70*10.5
90 95 100	75 80 85	10.5 10.5 12	11 11 12.5	SPGW90*75*10.5 SPGW95*80*10.5 SPGW100*85*12
105 110 115	90 95 100	12 12 12	12.5 12.5 12.5	SPGW105*90*12 SPGW110*95*12 SPGW115*100*12
120 125 130	105 102 107	12 15.5 15.5	12.5 16 16	SPGW120*105*12 SPGW125*102*15.5 SPGW130*107*15.5
135 140 145	112 117 122	15.5 15.5 15.5	16 16 16	SPGW135*112*15.5 SPGW140*117*15.5 SPGW145*122*15.5
150 155 160	127 132 137	15.5 15.5 15.5	16 16 16	SPGW150*127*15.5 SPGW155*132*15.5 SPGW160*137*15.5
165 170 180	142 147 157	15.5 15.5 15.5	16 16 16	SPGW165*142*15.5 SPGW170*147*15.5 SPGW180*157*15.5
185 190 200	162 167 177	15.5 15.5 15.5	16 16 16	SPGW185*162*15.5 SPGW190*167*15.5 SPGW200*177*15.5
210 220 225	187 197 202	15.5 15.5 17	16 16 17.5	SPGW210*187*15.5 SPGW220*197*15.5 SPGW225*202*15.5
230 240 250	207 217 222	17 17 17	17.5 17.5 17.5	SPGW230*207*15.5 SPGW240*217*15.5 SPGW250*222*17
260 270 280	232 242 252	17 17 17	17.5 17.5 17.5	SPGW260*232*17 SPGW270*242*17 SPGW280*252*17
300 320 350	272 292 322	17 17 17	17.5 17.5 17.5	SPGW300*272*17 SPGW320*292*17 SPGW350*322*17

Company Features
1. Dms Seals Technology Co.,limited has developed to be a internationally leading company in the hydraulic piston seals suppliers field. As a top cylinder oil seal supplier, Dms Seals Technology Co.,limited has been making much progress in the market. Dms Seals Technology Co.,limited always supplies high quality cylinder rod seal as a professional manufacturer.
2. We have assembled a knowledgeable staff. Having the experience and skills to take projects from concept to completion, they make the company capable of meeting customer needs. We have an professional team with years of experience. They ensure that orders are processed and commitments are met in a timely and cost-efficient manner. With strong scientific research and development capacities, the technical capabilities of Dms Seals Technology Co.,limited are widely recognized. The company is recognized by the Chinese government and the public for its quality, reliability, and cost-efficiency in an ever-increasing number of markets worldwide. The award of the advanced enterprise of quality management system is powerful evidence to prove this.
3. Dms Seals Technology Co.,limited's focus on customized and innovative buy hydraulic seals to meet our customers’ needs will continue to be our driving force. Contact! DMS Seal Manufacturer has made up its mind to win the molded seals market. Contact! Since its entry into the oversea market, Dms Seals Technology Co.,limited has been adhering to the high standard. Contact!
