DMS Seals hydraulic piston seals suppliers for sale for pressure work and sliding high speed occasions

Company Advantages
1. Before production, the electrode materials of DMS Seals are carefully handled to prevent them from coming into contact with each other. Because contamination between the anode and cathode materials will ruin the battery.
2. All DMS Seals are tested on installation by our professional engineers to ensure that they provide years of safe and enjoyable use.
3. DMS Seals goes through a series of sophisticated treatment to ensure its high quality. For example, the heat-treated process is conducted to eliminate any toxic elements.
4. The manufacture of DMS Seals hydraulic piston seals suppliers meets a meet environmental standards. The improvements in its design contribute to energy recovery and emission reduction.
5. Experts have testified to the excellent performance of hydraulic piston seals suppliers form Dms Seals Technology Co.,limited.
6. The excellent properties in make hydraulic piston seals suppliers have wider applications.
7. The product is well received in the market for its high performance and reliable quality.
8. Strict quality inspections are carried out before delivery to increase its qualification ratio.
9. This product is in compliance with the highest quality standards.
10. The product looks great and clean. It is especially great for families and groups of friends to create fun and memories. - One of the visitors says.
11. Many of my customers love it and say the quality is good and it seems like a high-end gift. - Say one of our purchasers.
12. The product has no threats to the safety of food. People love it because they know the food barbequed by it has little health issues.
13. The product can result in important economic and environmental benefits for residential or commercial real estate projects, hotels, hospitals, universities, and offices.

1. Installation Recommendation

2. Installation Sizes

Rod Diameter	Outer Diameter	Groove Width	Install Chamfer	Radius	Radial Clearance                S max.
d f8	D H8	L+0.2	L1	R1	10MPa	20MPa	40MPa
50-69.9	d+15.0	7.5	5.0	0.4	0.5	0.4	0.3
70-149.9	d+20.0	10.1	6.0	0.4	0.7	0.5	0.4
200-244.9	d+25.0	12.5	8.5	0.4	0.8	0.6	0.5
245-519.9	d+30.0	15.0	10.0	0.8	0.9	0.7	0.6
520-769.9	d+35.0	17.5	13.0	1.2	1.0	0.8	0.7
770-1500	d+40.0	20.0	15.0	1.2	1.0	0.8	0.7

3. Application and properties

Applied for larger diameter piston rods and heavy-duty hydraulic rod sealing system in hard working conditions. High pressure resistance, excellent resistance to gap extrusion, wear-resisting.

4. Standard materials

Sealing ring: filled PTFE

O-Ring: NBR / FKM



5. Working Conditions

Working  Conditions
Diameter Range	Pressure Range	Temperature Range	Speed	Medium
3 - 1600mm	0 - 60MPa	-30℃ +100℃	5 m/s	hydraulic oil, flame retardant liquid, water, gas

6. Installation Dimensions

Rod Dia.	Outer Dia.	Groove Width	Order No.
d f8	D H8	L+0.2
50 60 70	65 75 85	7.5 7.5 7.5	GSJ-W50*65*7.5 GSJ-W60*75*7.5 GSJ-W70*85*7.5
75 80 100	95 100 120	10 10 10	GSJ-W75*95*10 GSJ-W80*100*10 GSJ-W100*120*10
110 115 120	130 135 140	10 10 10	GSJ-W110*130*10 GSJ-W115*135*10 GSJ-W120*140*10
130 140 145	150 160 165	10 10 10	GSJ-W130*150*10 GSJ-W140*160*10 GSJ-W145*165*10
150 160 170	170 180 190	10 10 10	GSJ-W150*170*10 GSJ-W160*180*10 GSJ-W170*190*10
175 180 200	195 200 220	10 10 10	GSJ-W175*195*10 GSJ-W180*200*10 GSJ-W200*220*10
230 240 250	255 265 275	12.5 12.5 12.5	GSJ-W230*255*12.5 GSJ-W240*265*12.5 GSJ-W250*275*12.5
260 265 270	285 290 295	12.5 12.5 12.5	GSJ-W260*285*12.5 GSJ-W265*290*12.5 GSJ-W270*295*12.5
280 290 300	305 315 325	12.5 12.5 12.5	GSJ-W280*305*12.5 GSJ-W290*315*12.5 GSJ-W300*325*12.5

Company Features
1. Dms Seals Technology Co.,limited is a supplier of and has been focusing on product manufacturing in this industry for many years. Dms Seals Technology Co.,limited is a manufacturing company in China. With extensive industry experience, we set the standard for the market. Dms Seals Technology Co.,limited is a well-known manufacturer of hydraulic piston seals suppliers in China. We have the specialist knowledge and experience to lead the market. Having been involved in the R&D, design, and production of , Dms Seals Technology Co.,limited has gained a rich manufacturing experience. With many years of product design and manufacturing experience, Dms Seals Technology Co.,limited can provide the best .
2. Dms Seals Technology Co.,limited has its own R&D laboratory for developing and producing hydraulic cylinder rebuild parts . DMS Seals has complete quality control system to produce fluoro rubber seal . To increase its competence in the market, DMS Seals largely invested into optimizing the technology to produce hydraulic cylinder seals and wipers . The establishment of a technology center promotes the development of DMS Seals. Dms Seals Technology Co.,limited has strong technological base and manufacturing capacity.
3. We will make sure our production activities will not pose any risk to the environment. We will treat hazardous substances and emissions in an appropriate and serious manner before we throw out or discharge them. We are acting responsibly during our operation. We work to reduce our demand for energy through conservation, improving the energy efficiency of equipment and processes. We work hard to minimize the environmental impact during our production. We seek new ways to optimize our production processes by reducing waste and energy consumption. We stick to sustainable development. We keep eco-friendly manufacturing, reduce waste through reuse and building quality products that last and thereby promoting sustainability. Our factory is given improvement targets. Every year we ring-fence capital investment for projects that reduce energy, CO2 emissions, water use, and waste that deliver the strongest environmental and financial benefits.

DMS Seals hydraulic piston seals suppliers for sale for pressure work and sliding high speed occasions

hydraulic piston seals suppliers

Type:
