DMS Seals hydraulic rod seals online for sale for pressure work and sliding high speed occasions

Company Advantages
1. hydraulic rod seals online mainly contains material.
2. The production of hydraulic rod seals online always take into account.
3. This hydraulic rod seals online is developed using premium quality material in compliance with the international quality standards.
4. The product is applied to provide excellent and efficient performance.
5. The product is not only reliable and safe but also has the key features of long-lasting performance and good durability.
6. The product discloses a number of advantages, such as long-lasting stable performance, long service life, and so on.
7. The product is highly praised among clients due to the above advantages and is used widely in the market currently.
8. The product shows great value in the industry and is bound to meet the specific requirements of customers.
9. This product has received more popularity around the world.
10. Over the years, the product continues to upgrade and get the praise of the majority of users.

1. Installation Recommendation

2. Installation Sizes

Rod Diameter d e8	Groove Diameter D H9	Groove Width L D10	H
20-56	d+10	16	15
57-140	d+13	16	15
＞140	d+15	16	15

3. Application and properties

Suitable for tandem type internal sealing, and can be used as fluid sealing and dust sealing simultaneously. Excellent sealing effect can be achieved in case of no pressure. Easy installation, wear-resisting, anti extrusion, low friction, non stick slip phenomenon.

4. Standard materials

Sealing ring: filled PTFE

O-Ring: NBR / PU

5. Working Conditions

Working  Conditions
Diameter Range	Pressure Range	Temperature Range	Speed	Medium
3 - 1600mm	0 - 25MPa	-30℃ + 100℃	1 m/s	hydraulic oil, flame retardant liquid, water, gas

6. Installation Dimensions

d e8	D1 H9	H	L D10	e	Order No.
50 55 56	60 65 66	15 15 15	16 16 16	6 6 6	MDI50*60*15 MDI55*65*15 MDI56*66*15
60 63 65	73 76 78	15 15 15	16 16 16	7 7 7	MDI60*73*15 MDI63*76*15 MDI65*78*15
70 72 75	83 85 88	15 15 15	16 16 16	7 7 7	MDI70*83*15 MDI72*85*15 MDI75*88*15
80 85 90	93 98 103	15 15 15	16 16 16	7 7 7	MDI80*93*15 MDI85*98*15 MDI90*103*15
95 100 105	108 113 118	15 15 15	16 16 16	7 7 10	MDI95*108*15 MDI100*113*15 MDI105*118*15
110 110 115	120 123 128	15 15 15	16 16 16	10 10 10	MDI110*120*15 MDI110*123*15 MDI115*128*15
120 125 130	133 138 143	15 15 15	16 16 16	10 10 10	MDI120*133*15 MDI125*138*15 MDI130*143*15
140 150 150	153 162 165	15 15 15	16 16 16	10 10 10	MDI140*153*15 MDI150*162*15 MDI150*165*15
160 165 170	175 180 185	15 15 15	16 16 16	10 10 10	MDI160*175*15 MDI165*180*15 MDI170*185*15
180 185 190	195 200 205	15 15 15	16 16 16	10 10 10	MDI180*195*15 MDI185*200*15 MDI190*205*15

Company Features
1. Apart from manufacturing hydraulic rod seals online , we also specialize in the designing and sales of the products. By the advantage of technology, Dms Seals Technology Co.,limited has gained high reviews for its hydraulic oil seal sizes . Dms Seals Technology Co.,limited's products have been available in Chinese market for more decades of years. As one of the most well-known exporter, Dms Seals Technology Co.,limited is going to increase its capacity and grow stronger. hydraulic seal kits suppliers from Dms Seals Technology Co.,limited dominates the main market.
2. Our factory has established a standardized quality management system. This quality management system enables us to achieve high-quality control in the aspects of raw materials selections, workmanship handling, automation level, and manpower control. Dms Seals Technology Co.,limited has a dedicated and professional design team. We have reliable manufacturing facilities. They get ongoing investments and continuously take in advanced machines. They offer the company state-of-the-art manufacturing capabilities.
3. To survive in market of hydraulic rod wipers , Dms Seals Technology Co.,limited will never forget that quality is key point. Welcome to visit our factory! The eternal tenet for Dms Seals Technology Co.,limited is to in the process of . Welcome to visit our factory! is the cardinal service principle of Dms Seals Technology Co.,limited. Welcome to visit our factory! is a fundamental tenet of an efficient development for Dms Seals Technology Co.,limited. Welcome to visit our factory!
