hydraulic rod seals company to high and low speed

Company Advantages
1. DMS Seal Manufacturer hydraulic rod seals undergoes a series of processing technics which are up to the newest standards in the industry including high-temperature cooling, heating, disinfection, and drying.
2. DMS Seal Manufacturer is strictly inspected. It is carried out by our QC team who checks its biocompatibility, sanitation, wear resistance, and chemical resistance.
3. DMS Seal Manufacturer has to go through a series of production processes before it becomes a beautiful gift, including material cleaning, drying, cutting, pattern making, polishing, etc.
4. Every ingredient of DMS Seal Manufacturer has undergone a strict antimicrobial effectiveness test and is scientifically assessed by our professional QC team.
5. The product is featured by excellent performance and reliable quality.
6. The product is in compliance with stringent quality specifications.
7. The product meets with the industrial safety and quality standards.
8. The product only needs little cost to run. People are able to lower their utility bill in the long run.
9. The product is soft and easily stretches, which enables it to be comfortable fabrics to wear or use in daily life.
10. The product is an ideal solution for spaces that require a mobile layout that can adjust to changing conditions and needs.
11. Its clean and straight lines enhance the aesthetical appeal, providing people with a comfortable and relaxed bathing environment.
12. This product has advantages of easy use, installation, and volume of storage and transportation, taking the hassle out of any problems.

1. Installation Recommendation

2. Installation Sizes

Rod Diameter d e8	Groove Diameter D H9	Groove Width L D10	H
20-56	d+10	16	15
57-140	d+13	16	15
＞140	d+15	16	15

3. Application and properties

Suitable for tandem type internal sealing, and can be used as fluid sealing and dust sealing simultaneously. Excellent sealing effect can be achieved in case of no pressure. Easy installation, wear-resisting, anti extrusion, low friction, non stick slip phenomenon.

4. Standard materials

Sealing ring: filled PTFE

O-Ring: NBR / PU

5. Working Conditions

Working  Conditions
Diameter Range	Pressure Range	Temperature Range	Speed	Medium
3 - 1600mm	0 - 25MPa	-30℃ + 100℃	1 m/s	hydraulic oil, flame retardant liquid, water, gas

6. Installation Dimensions

d e8	D1 H9	H	L D10	e	Order No.
50 55 56	60 65 66	15 15 15	16 16 16	6 6 6	MDI50*60*15 MDI55*65*15 MDI56*66*15
60 63 65	73 76 78	15 15 15	16 16 16	7 7 7	MDI60*73*15 MDI63*76*15 MDI65*78*15
70 72 75	83 85 88	15 15 15	16 16 16	7 7 7	MDI70*83*15 MDI72*85*15 MDI75*88*15
80 85 90	93 98 103	15 15 15	16 16 16	7 7 7	MDI80*93*15 MDI85*98*15 MDI90*103*15
95 100 105	108 113 118	15 15 15	16 16 16	7 7 10	MDI95*108*15 MDI100*113*15 MDI105*118*15
110 110 115	120 123 128	15 15 15	16 16 16	10 10 10	MDI110*120*15 MDI110*123*15 MDI115*128*15
120 125 130	133 138 143	15 15 15	16 16 16	10 10 10	MDI120*133*15 MDI125*138*15 MDI130*143*15
140 150 150	153 162 165	15 15 15	16 16 16	10 10 10	MDI140*153*15 MDI150*162*15 MDI150*165*15
160 165 170	175 180 185	15 15 15	16 16 16	10 10 10	MDI160*175*15 MDI165*180*15 MDI170*185*15
180 185 190	195 200 205	15 15 15	16 16 16	10 10 10	MDI180*195*15 MDI185*200*15 MDI190*205*15

Company Features
1. Dms Seals Technology Co.,limited is one of the earliest and largest hydraulic rod seals manufacturer. The main focus of DMS Seal Manufacturer is to incorporate design, fabrication, sales and service together. Supplying a full range of rod seal kit , Dms Seals Technology Co.,limited is internationally famous.
2. Our company has garnered a huge client base across the world. Without compromising the quality of the product variety, increasing market share, reasonable price, high quality and superior service with an understanding of our customers help us to retain these clients. We have been certified under the ISO 9001 international management system. This system guarantees an efficient management process in place to monitor the production process and opens the door for continuous improvement. All or part of our products comply with international quality standards and are greatly appreciated in a variety of different markets throughout the whole world. As a result of our high quality products, we have gained a global sales network reaching Europe, America, Asia.
3. Always keeps integrity in mind is a fundamental corporate culture of Dms Seals Technology Co.,limited. Inquiry! Dms Seals Technology Co.,limited has been committed to technological innovation and quality improvement for hydraulic seal kit manufacturers . Inquiry! DMS Seal Manufacturer dreams to surpass many companies in the this industry. Inquiry!
