DMS SEALS TECHNOLOGY CO.,LIMITED

The Professional Sealing Solution Supplier(O Ring Suppliers & Oil Seal Manufacturers).

DMS Seals - Hydraulic Seals and Oil Ring Seals Manufacturer & Supplier

Mail to: sales@dmsseals.com tel:+86-757-86235767

hydraulic rod seals hydraulic oring rod DMS Seal Manufacturer Brand

Diameter Range:

3-1600mm

Pressure Range:

0-35MPa

Temperature Range:

-30℃+200℃

Speed:

1.5m/s

Medium:

general hydraulic oil, water glycol hydraulic oil, oil / water emulsion type hydraulic oil.

Inquiry

Company Advantages
1. We are specialized in offering our clients an excellent array of rod seals.
2. Dms Seals Technology Co.,limited is familiar with the sales network in hydraulic rod seals area. DMS Seal manufacturer provides good quality and competitive price hydraulic seals
3. Dms Seals Technology Co.,limited have specialized in high tolerance O Ring Manufacturers machining for hydraulic rod seals years. As a modern sealing technology company, DMS Seal manufacturer has a wealth of experience.
4. We have installed sophisticated machinery which allow us in delivering the o-ring seal within the specified time frame. DMS Seal manufacturer was established in 2008 and now has more than 10 years professional experience
5. DMS o-ring seal has advanced machines and equipment for its production. It is our advanced piston rod seal that guarantees the great operation of rod seals,hydraulic rod seals online.

Installation Recommendation

undefined

Application and properties

Applicable to a wide range of pressure work and sliding high speed occasions. Standard combined seal. Low friction, strong wear resistance.

Standard materials

Sealing ring: filled PTFE

O-Ring: NBR / FKM

Working Conditions

Working Conditions
Diameter Range	Pressure Range	Temperature Range	Speed	Medium
3-1600mm	0-35MPa	-30℃+200℃	1.5 m/s	general hydraulic oil, water glycol hydraulic oil, oil / water emulsion type hydraulic oil.

Installation Dimensions

Nominal Size of Packing, and Housing dimensions				Order No.
d	D	H	L +0.2	Order No.
12 14 16	18 20 22	3.0 3.0 3.0	3.2 3.2 3.2	SPNO12183.2 SPNO14203.2 SPNO16223.2
18 20 22	24 26 31	3.0 3.0 3.8	3.2 3.2 4	SPNO18243.2 SPNO20263.2 SPNO22314
25 28 30	34 37 39	3.8 3.8 3.8	4 4 4	SPNO25344 SPNO28374 SPNO30394
32 36 40	41 45 49	3.8 3.8 3.8	4 4 4	SPNO32414 SPNO36454 SPNO40494
45 50 56	54 65 71	3.8 6.3 6.3	4 6.5 6.5	SPNO45544 SPNO50656.5 SPNO56716.5
60 63 70	75 78 85	6.3 6.3 6.3	6.5 6.5 6.5	SPNO60756.5 SPNO63786.5 SPNO70856.5
75 80 85	90 95 100	6.3 6.3 6.3	6.5 6.5 6.5	SPNO75906.5 SPNO80956.5 SPNO851006.5
90 95 100	105 110 115	6.3 6.3 6.3	6.5 6.5 6.5	SPNO901056.5 SPNO951106.5 SPNO1001156.5
105 110 115	120 125 130	6.3 6.3 6.3	6.5 6.5 6.5	SPNO1051206.5 SPNO1101256.5 SPNO1151306.5
120 125 130	135 140 145	6.3 6.3 6.3	6.5 6.5 6.5	SPNO1201356.5 SPNO1251406.5 SPNO1301456.5
135 140 145	150 155 160	6.3 6.3 6.3	6.5 6.5 6.5	SPNO1351506.5 SPNO1401556.5 SPNO1451606.5
150 160 170	170 180 190	9.8 9.8 9.8	10 10 10	SPNO15017010 SPNO16018010 SPNO17019010

Installation Dimensions

Company Features
1. Dms Seals Technology Co.,limited's forward-looking technology helps its customers stay ahead of the industry.
2. DMS Seal Manufacturer offers quality rod seals at the economical price. Inquire now!

we welcome custom designs and ideas and is able to cater to the specific requirements. for more information, please visit the website or contact us directly with questions or inquiries.
