hydraulic rod seals Supply to high and low speed

Company Advantages
1. The quality of DMS Seal Manufacturer is assured by a number of standards applicable to furniture. They are BS 4875, NEN 1812, BS 5852：2006 and so forth.
2. DMS Seal Manufacturer has passed recognized tests. These tests include fiber composition testing, fabric construction testing, dimension stability testing, and flammability testing.
3. DMS Seal Manufacturer is tested from different aspects. It has gone through both physical and mechanical tests, such as color shading, rub colorfastness, odor testing, and burn tests.
4. DMS Seal Manufacturer hydraulic rod seals undergoes a wide range of manufacturing steps. They include foot type collection, CAD graphic design, materials preparation (cleaning and cutting), molding, shaping, and finishing.
5. DMS Seal Manufacturer must go through some basic tests. These tests include fabric construction testing, dimensional stability testing, breathability testing, and flammability testing.
6. hydraulic rod seals have been widely used in for their features.
7. Compared with the traditional hydraulic rod seals , has a series of advantages.
8. With such characteristic, is an excellent hydraulic rod seals .
9. With this product, the overall feel of the space will be a harmonious blend of all the elements that creates a well-furnished whole.
10. This product is not there merely to serve as decorative or functional pieces. It can bring people joy and comfort.
11. This product can greatly fit the shape of people's bodies. It will not distort their silhouette or restrict their movements.

1. Installation Recommendation

2. Installation Sizes

Rod Diameter	Outer Diameter	Groove Width	Install Chamfer	Radius	Radial Clearance                S max.
d f8	D H8	L+0.2	L1	R1	10MPa	20MPa	40MPa
50-69.9	d+15.0	7.5	5.0	0.4	0.5	0.4	0.3
70-149.9	d+20.0	10.1	6.0	0.4	0.7	0.5	0.4
200-244.9	d+25.0	12.5	8.5	0.4	0.8	0.6	0.5
245-519.9	d+30.0	15.0	10.0	0.8	0.9	0.7	0.6
520-769.9	d+35.0	17.5	13.0	1.2	1.0	0.8	0.7
770-1500	d+40.0	20.0	15.0	1.2	1.0	0.8	0.7

3. Application and properties

Applied for larger diameter piston rods and heavy-duty hydraulic rod sealing system in hard working conditions. High pressure resistance, excellent resistance to gap extrusion, wear-resisting.

4. Standard materials

Sealing ring: filled PTFE

O-Ring: NBR / FKM



5. Working Conditions

Working  Conditions
Diameter Range	Pressure Range	Temperature Range	Speed	Medium
3 - 1600mm	0 - 60MPa	-30℃ +100℃	5 m/s	hydraulic oil, flame retardant liquid, water, gas

6. Installation Dimensions

Rod Dia.	Outer Dia.	Groove Width	Order No.
d f8	D H8	L+0.2
50 60 70	65 75 85	7.5 7.5 7.5	GSJ-W50*65*7.5 GSJ-W60*75*7.5 GSJ-W70*85*7.5
75 80 100	95 100 120	10 10 10	GSJ-W75*95*10 GSJ-W80*100*10 GSJ-W100*120*10
110 115 120	130 135 140	10 10 10	GSJ-W110*130*10 GSJ-W115*135*10 GSJ-W120*140*10
130 140 145	150 160 165	10 10 10	GSJ-W130*150*10 GSJ-W140*160*10 GSJ-W145*165*10
150 160 170	170 180 190	10 10 10	GSJ-W150*170*10 GSJ-W160*180*10 GSJ-W170*190*10
175 180 200	195 200 220	10 10 10	GSJ-W175*195*10 GSJ-W180*200*10 GSJ-W200*220*10
230 240 250	255 265 275	12.5 12.5 12.5	GSJ-W230*255*12.5 GSJ-W240*265*12.5 GSJ-W250*275*12.5
260 265 270	285 290 295	12.5 12.5 12.5	GSJ-W260*285*12.5 GSJ-W265*290*12.5 GSJ-W270*295*12.5
280 290 300	305 315 325	12.5 12.5 12.5	GSJ-W280*305*12.5 GSJ-W290*315*12.5 GSJ-W300*325*12.5

Company Features
1. Dms Seals Technology Co.,limited stands out in the market and becomes the first choice when it comes to the developing and manufacturing of . Established years ago, Dms Seals Technology Co.,limited is a reliable Chinese company with a speciality in the design and manufacture of . Applying our experience gained from providing high quality , Dms Seals Technology Co.,limited has proven beneficial to all of our customers. As a reputable manufacturer of in the Chinese market, Dms Seals Technology Co.,limited has earned a good reputation for designing and manufacturing. Dms Seals Technology Co.,limited has extensive experience in manufacturing . We are famous in the industry for our strong capabilities.
2. Our hydraulic rod seals enjoys a good reputation because of its high quality. DMS Seal Manufacturer's factory has many product R&D engineers and pattern-making engineers. As is known to all us that DMS Seal Manufacturer has made a great achievement since the launch of hydraulic rod seals . Dms Seals Technology Co.,limited gets the certificate of ISO9001 quality management system.
3. We unswervingly provide superior pneumatic rod seals to every customer. Please contact. DMS Seal Manufacturer will constantly providing high quality hydraulic rod seals online . Please contact. As a leading company, Dms Seals Technology Co.,limited is ambitious to produce higher quality push rod seal. Please contact.
