DMS Seals - Hydraulic Seals and Oil Ring Seals Manufacturer & Supplier
hydraulic seal rod DMS Seal Manufacturer Brand rod seals
1. The rod seals facility can hydraulic rod seals and you can specify piston rod seal.DMS Seal manufacturer provides good quality and competitive price hydraulic seals
2. It is of great importance for DMS Seal Manufacturer to provide exquisite customer service. DMS o-ring seal has advanced machines and equipment for its production
3. hydraulic rod seals are widely used for hydraulic rod seals online. Quality control of the seals is the basis for DMS Seals
4. DMS Seals' production equipment and test equipment are on the leading level in the industry. O Ring Manufacturers,rod seal catalogue, by adopting pneumatic rod seals, is conducive to showing the uniqueness of this product.
d e8 | D H9 | L D10 | H | Ø - range | e |
22-39 | d+7.2 | 4.0 | 3.5 | 20-56 | 6 |
40-79 | d+10.0 | 5.0 | 4.5 | 60-100 | 7 |
80-100 | d+13.8 | 7.5 | 7.0 | 105-290 | 10 |
＞100-250 | d+20.0 | 10.0 | 9.5 | 300-630 | 15 |
＞250-600 | d+30.0 | 15.0 | 14.5 | ||
＞600 | d+40.0 | 20.0 | 19.5 |
Application and properties
L-Ring support and guide to ensure a tight sealing environment. Easy installation, wear resistance, anti extrusion, low friction, non stick slip phenomenon.
Standard materials
Sealing ring: filled PTFE
O-Ring: NBR / FKM
L-Ring: POM / PA
Working Conditions | ||||
Diameter Range | Pressure Range | Temperature Range | Speed | Medium |
3-1600mm | 0-45MPa | -30℃+100℃ | 1 m/s | hydraulic oil, flame retardant liquid, water, gas |
d e8 | D1 H9 | H | L D10 | e | Order No. |
22 | 29.2 | 3.5 | 4 | 6 | RDI22*29.2*3.5 |
30 | 37.2 | 3.5 | 4 | 6 | RDI30*37.2*3.5 |
36 | 43.2 | 3.5 | 4 | 6 | RDI36*43.2*3.5 |
45 | 55 | 4.5 | 5 | 6 | RDI45*55*4.5 |
56 | 66 | 4.5 | 5 | 6 | RDI56*66*4.5 |
65 | 75 | 4.5 | 7.5 | 7 | RDI65*75*4.5 |
75 | 85 | 4.5 | 7.5 | 7 | RDI75*85*4.5 |
90 | 103.8 | 7.0 | 7.5 | 7 | RDI90*103.8*7.0 |
