RDI - PTFE Hydraulic Rod Seal with NBR/FKM O-Ring

Company Advantages
1. DMS Seal Manufacturer hydraulic rod seals is manufactured by first-rate raw materials from the leading suppliers. The production of the raw materials strictly adheres to international quality standards.
2. The production speed of DMS Seal Manufacturer hydraulic rod seals is guaranteed by highly advanced production technology.
3. Standard production: DMS Seal Manufacturer O Ring Manufacturers is produced in line with production standards. These standards are up to both domestic and international standards and contribute to the fine craftsmanship of this product.
4. O Ring Manufacturers is designed and assembled in state-of-the-art production plant which meets the latest lean manufacturing and quality standards.
5. The product can work in extreme conditions. It performs stably under high and low temperature, as well as in a condition where is full of dust and radiation.
6. The product features high acoustic insulation. The sound absorptive materials have been installed inside to further increase its STC rating.
7. The product is 100% toxic free. It has been clinically tested in terms of materials or parts, and it has proved that no toxic substances are found.
8. The product has a precise dimension. After it is produced, it will be checked using the dimension measuring equipment or coordinate measuring machine.
9. It is beautiful to look at, exciting to install, and a delight to own. And it sounds great in the rain.
10. If one is in search of a projector screen that’s suitable for public displays, home theatre, office presentations as well as classroom training, then this product is the answer.
11. The product simplifies life by reducing the number of steps between people and their final goal. It brings much convenience and leisure.
12. It brings aesthetics and design flexibility. It gives architects and other specifiers the flexibility to create a building with a unique look.

1. Installation Recommendation

2. Installation Sizes

d e8	D H9	L D10	H
22-39	d+7.2	4.0	3.5
40-79	d+10.0	5.0	4.5
80-100	d+13.8	7.5	7.0
＞100-250	d+20.0	10.0	9.5
＞250-600	d+30.0	15.0	14.5
＞600	d+40.0	20.0	19.5

3. Application and properties

L-Ring support and guide to ensure a tight sealing environment. Easy installation, wear resistance, anti extrusion, low friction, non stick slip phenomenon.



4. Standard materials

Sealing ring: filled PTFE

O-Ring: NBR / FKM

L-Ring: POM / PA

5. Working Conditions

Working  Conditions
Diameter Range	Pressure Range	Temperature Range	Speed	Medium
3 - 1600mm	0 - 45MPa	-30℃ +100℃	1 m/s	hydraulic oil, flame retardant liquid, water, gas

6. Installation Dimensions

d e8	D1 H9	H	L D10	e	Order No.
22 25 28	29.2 32.2 35.2	3.5 3.5 3.5	4 4 4	6 6 6	RDI22*29.2*3.5 RDI25*32.2*3.5 RDI28*35.2*3.5
30 32 35	37.2 39.2 42.2	3.5 3.5 3.5	4 4 4	6 6 6	RDI30*37.2*3.5 RDI32*39.2*3.5 RDI35*42.2*3.5
36 40 42	43.2 50 52	3.5 4.5 4.5	4 5 5	6 6 6	RDI36*43.2*3.5 RDI40*50*4.5 RDI42*52*4.5
45 50 55	55 60 65	4.5 4.5 4.5	5 5 5	6 6 6	RDI45*55*4.5 RDI50*60*4.5 RDI55*65*4.5
56 60 63	66 70 73	4.5 4.5 4.5	5 5 7.5	6 7 7	RDI56*66*4.5 RDI60*70*4.5 RDI63*73*4.5
65 70 72	75 80 82	4.5 4.5 4.5	7.5 7.5 7.5	7 7 7	RDI65*75*4.5 RDI70*80*4.5 RDI72*82*4.5
75 80 85	85 93.8 98.8	4.5 7.0 7.0	7.5 7.5 7.5	7 7 7	RDI75*85*4.5 RDI80*93.8*7.0 RDI85*98.8*7.0
90 95 100	103.8 108.8 113.8	7.0 7.0 7.0	7.5 7.5 7.5	7 7 7	RDI90*103.8*7.0 RDI95*108.8*7.0 RDI100*113.8*7.0
105 110 115	125 130 135	9.5 9.5 9.5	10 10 10	10 10 10	RDI105*125*9.5 RDI110*130*9.5 RDI115*135*9.5
120 125 130	140 145 150	9.5 9.5 9.5	10 10 10	10 10 10	RDI120*140*9.5 RDI125*145*9.5 RDI130*150*9.5
