rod ptfe rod seals hydraulic DMS Seal Manufacturer Brand

Diameter Range:

3-1600mm

Pressure Range:

0-35MPa

Temperature Range:

-30℃+200℃

Speed:

1.5m/s

Medium:

general hydraulic oil, water glycol hydraulic oil, oil / water emulsion type hydraulic oil.

Inquiry

Company Advantages
1. Seal we produced has applications in a wide range of fields. Owing to its various quality attributes, provided hydraulic rod seals is highly appreciated by DMS Seal Manufacturer clients.
2. Dms Seals Technology Co.,limited's customer service always works on a professional level. DMS Seal manufacturer was established in 2008 and now has more than 10 years professional experience
3. The offered rod seals items and furniture are manufactured using premium quality piston rod seal and sophisticated technology. DMS Seals implements and optimizes its quality control systems
4. The test results indicate that hydraulic rod seals has several merits such as hydraulic rod seals online. To reduce costs with high-efficiency work is the DMS's purpose

Installation Recommendation

undefined

Application and properties

Applicable to a wide range of pressure work and sliding high speed occasions. Standard combined seal. Low friction, strong wear resistance.

Standard materials

Sealing ring: filled PTFE

O-Ring: NBR / FKM

Working Conditions

Working Conditions
Diameter Range	Pressure Range	Temperature Range	Speed	Medium
3-1600mm	0-35MPa	-30℃+200℃	1.5 m/s	general hydraulic oil, water glycol hydraulic oil, oil / water emulsion type hydraulic oil.

Installation Dimensions

Nominal Size of Packing, and Housing dimensions				Order No.
d	D	H	L +0.2	Order No.
12 14 16	18 20 22	3.0 3.0 3.0	3.2 3.2 3.2	SPNO12183.2 SPNO14203.2 SPNO16223.2
18 20 22	24 26 31	3.0 3.0 3.8	3.2 3.2 4	SPNO18243.2 SPNO20263.2 SPNO22314
25 28 30	34 37 39	3.8 3.8 3.8	4 4 4	SPNO25344 SPNO28374 SPNO30394
32 36 40	41 45 49	3.8 3.8 3.8	4 4 4	SPNO32414 SPNO36454 SPNO40494
45 50 56	54 65 71	3.8 6.3 6.3	4 6.5 6.5	SPNO45544 SPNO50656.5 SPNO56716.5
60 63 70	75 78 85	6.3 6.3 6.3	6.5 6.5 6.5	SPNO60756.5 SPNO63786.5 SPNO70856.5
75 80 85	90 95 100	6.3 6.3 6.3	6.5 6.5 6.5	SPNO75906.5 SPNO80956.5 SPNO851006.5
90 95 100	105 110 115	6.3 6.3 6.3	6.5 6.5 6.5	SPNO901056.5 SPNO951106.5 SPNO1001156.5
105 110 115	120 125 130	6.3 6.3 6.3	6.5 6.5 6.5	SPNO1051206.5 SPNO1101256.5 SPNO1151306.5
120 125 130	135 140 145	6.3 6.3 6.3	6.5 6.5 6.5	SPNO1201356.5 SPNO1251406.5 SPNO1301456.5
135 140 145	150 155 160	6.3 6.3 6.3	6.5 6.5 6.5	SPNO1351506.5 SPNO1401556.5 SPNO1451606.5
150 160 170	170 180 190	9.8 9.8 9.8	10 10 10	SPNO15017010 SPNO16018010 SPNO17019010

Installation Dimensions

Company Features
1. Adversity Successfully Overcome Is The Highest Glory. DMS Seal Manufacturer Offers A Wide Range Of rod seals, hydraulic rod seals, piston rod seal At Reasonable Price To Customers From All Over The World. Please Contact Us!
2. DMS Seal Manufacturer focuses on continuous technological innovation to improve products and services. Contact!

we welcome custom designs and ideas and is able to cater to the specific requirements. for more information, please visit the website or contact us directly with questions or inquiries.
