DMS Seals - Hydraulic Seals and Oil Ring Seals Manufacturer & Supplier
seal ptfe hydraulic rod seals DMS Seal Manufacturer Brand
- 's excellent sci-tech team are strong technical support for the production of products.
- runs a comprehensive service system covering from pre-sales to sales and after-sales. Customers can rest assured during the purchase.
- always strives for modern brand building and constant innovation and development. We promote sustainable development of production in the industry by establishing long-term management mechanism.
- Since the inception in , has been adhering to the business philosophy of 'quality determines sales, conscience determines fate' for years.
- At present, 's O-ring Seal are sold to all parts of the country and well received in the industry.
1. DMS Seals manufacturer owns a team of professional R&D group and skilled technicians. Backed by rich industry experience and market understanding, we are involved in offering a wide array of hydraulic rod seals to DMS Seal Manufacturer valued patrons.
2. rod seals can be used for a long time by virtue of large capacity and low self-discharge rate. Moreover, the excellent recharge acceptance makes it recycling and eco-friendly.
3. It is built to exceed manufacturing excellence standards. High-end talents and advanced technology have enabled DMS o-ring seal quality to reach the industry's leading level
4. DMS Seal Manufacturer attaches great importance to producing hydraulic rod seals with high quality. DMS Seal manufacturer is a technology enterprise which specialized in the R&D and production of seals
1. Installation Recommendation
2. Application and properties
The standard combination seal is suitable for a wide range of pressure work and sliding high speed occasions. Low friction, strong wear resistance.
3. Standard materials
Sealing ring: filled PTFE
O-Ring: NBR / FKM
4. Working Conditions
Working Conditions | ||||
Diameter Range | Pressure Range | Temperature Range | Speed | Medium |
6-1600mm | 0-35MPa | -30℃ +200℃ | 1.5 m/s | general hydraulic oil, water glycol Hydraulic oil and water emulsion type hydraulic oil. |
5. Installation Dimensions
Order No. | ||||
d | D | H | L +0.2 | |
18 20 22 | 27 29 31 | 4.3 4.3 4.3 | 4.5 4.5 4.5 | SPN18*27*4.3 SPN20*29*4.3 SPN22*31*4.3 |
27 31.5 47 | 36 40.5 60 | 4.3 4.3 7.3 | 4.5 4.5 7.5 | SPN27*36*4.3 SPN31.5*40.5*4.3 SPN47*60*7.3 |
53 60 65 | 66 73 78 | 7.3 7.3 7.3 | 7.5 7.5 7.5 | SPN53*66*7.3 SPN60*73*7.3 SPN65*78*7.3 |
70 75 80 | 83 88 93 | 7.3 7.3 7.3 | 7.5 7.5 7.5 | SPN70*83*7.3 SPN75*88*7.3 SPN80*93*7.3 |
90 100 110 | 103.4 113.4 123.4 | 7.3 7.3 7.3 | 7.5 7.5 7.5 | SPN90*103.4*7.3 SPN100*113.4*7.3 SPN110*123.4*7.3 |
120 130 140 | 133.4 143.4 153.4 | 7.3 7.3 7.3 | 7.5 7.5 7.5 | SPN120*133.4*7.3 SPN130*143.4*7.3 SPN140*153.4*7.3 |
Company Features
1. DMS Seal Manufacturer manufactures, produces and sells rod seals as a dominant supplier.
2. Dms Seals Technology Co.,limited has excellent high-quality research and development team and market management talents.
3. People oriented is a tenet that stimulates DMS Seal Manufacturer to do better. Check now!
