seal rod seal catalogue rod environment DMS Seal Manufacturer

Company Advantages
1. The unique design makes DMS Seal Manufacturer rod seal catalogue stand out among similar products.
2. The product has stable performance, long storage life and reliable quality.
3. A strict quality check on different quality parameters has been carried out throughout the whole production to ensure the product is completely defect-free and has good performance.
4. The competitiveness of the product lies in its tremendous economic benefits.
5. Supported by ingenious team, DMS Seal Manufacturer has highly recommended service team.

1. Installation Recommendation

2. Application and properties

The standard combination seal is suitable for a wide range of pressure work and sliding high speed occasions. Low friction, strong wear resistance.



3. Standard materials

Sealing ring: filled PTFE

O-Ring: NBR / FKM

4. Working Conditions

Working  Conditions
Diameter Range	Pressure Range	Temperature Range	Speed	Medium
6-1600mm	0-35MPa	-30℃ +200℃	1.5 m/s	general hydraulic oil, water glycol Hydraulic oil and water emulsion type hydraulic oil.



5. Installation Dimensions

Nominal Size of Packing, and Housing dimensions				Order No.
d	D	H	L +0.2
18 20 22	27 29 31	4.3 4.3 4.3	4.5 4.5 4.5	SPN18*27*4.3 SPN20*29*4.3 SPN22*31*4.3
27 31.5 47	36 40.5 60	4.3 4.3 7.3	4.5 4.5 7.5	SPN27*36*4.3 SPN31.5*40.5*4.3 SPN47*60*7.3
53 60 65	66 73 78	7.3 7.3 7.3	7.5 7.5 7.5	SPN53*66*7.3 SPN60*73*7.3 SPN65*78*7.3
70 75 80	83 88 93	7.3 7.3 7.3	7.5 7.5 7.5	SPN70*83*7.3 SPN75*88*7.3 SPN80*93*7.3
90 100 110	103.4 113.4 123.4	7.3 7.3 7.3	7.5 7.5 7.5	SPN90*103.4*7.3 SPN100*113.4*7.3 SPN110*123.4*7.3
120 130 140	133.4 143.4 153.4	7.3 7.3 7.3	7.5 7.5 7.5	SPN120*133.4*7.3 SPN130*143.4*7.3 SPN140*153.4*7.3

Company Features
1. Dms Seals Technology Co.,limited is a leading O Ring Manufacturers supplier dedicated to manufacturing.
2. Dms Seals Technology Co.,limited has attracted and nurtured a large number of senior technical management elites in o-ring seal industry.
3. The DMS Seal Manufacturer branded hydraulic rod seals is manufactured in strict accordance with international standards. We can promise high quality and remarkable service for rod seals . Call!
